— 16 —
OK NO GOOD NO GOODOK
4.4 Setting Paper
(1) Remove the printer cover.
(2) Ensure that the end of the paper is straight or incline as indicated in the diagram.
(3) Insert printing paper with the paper holder turned down in the arrow-indicated
direction, hold the core.
(4) Insert paper into the slot of the printer mechanism.
(5) Following turning-on of the power switch, as pressing the LF switch, take out
printing paper by 5 to 6 cm from the printer mechanism. As passing the paper
through paper outlet, mount the printer cover.
(LF switch works when SEL lamp is off.)
Note: Paper, if held aslant at the paper feed or the paper discharge side, may cause
paper jamming. On occurrence of the above, immediately turn off the power
and slowly pull out the jammed paper upright.
Paper holder
