Citizen CT-S651 Series

CT-S651 Series Service Manual
- 25 -
(4) Rotating center holes, press-formed projections and hooks at “LEVER R & L, CUTTER
RELEASE-02” and “SA, MAIN FRAME”
Rotating center holes, press-formed projections and hooks at “LEVER R & L, COVER
LOCK-02” and “SA, MAIN FRAME”
Slideways at “LEVER, COVER OPEN-02” and “SA, MAIN FRAME”
Outside of press-formed projections at
“SA, MAIN FRAME”
Inside of hooks at
“SA, MAIN FRAME”
Slideways at “SA, MAIN FRAME” and
“LEVER, COVER OPEN-02”
Rotating center holes at
“SA, MAIN FRAME”
Press-formed projections at
“SA, MAIN FRAME”
