SECTION 7 PARAMETERS
The scale has 6 parameters that can be set by the user plus a method of entering the
calibration section.
To set parameters press the FUNC key.
The display will show the first function, "F0 H-L".
Pressing the TARE/+ will cycle through the other functions.
Pressing ZERO/ENTER will allow you to set the function. It may be necessary to
either use TARE/+ or set a value using the SMPL/" key to move the active digit and
then using the TARE/! key to increment a digit, followed by the ZERO/ENTER key
to enter the value. Use the PRINT/ESC key to leave a parameter unchanged.
For example when the display shows “F0 H-L” press the ZERO/ENTER key to
begin.
The display will show “Set Lo”, press the ZERO/ENTER key to set the low limit, or
press the TARE/+ to skip to the next parameter, “Set Hi” for setting the high limit.
After pressing the ZERO/ENTER key to set a limit, use the the SMPL" keys to
change the flashing digit, then use the TARE/! key to increment the flashing digit.
Continue to the next digit and set it as needed.
When all digits have been set press the ZERO/ENTER key to store the value. The
display will go back to the parameter just set, i.e. “Set Lo”. Advance to another
parameter if needed or press the PRINT/ESC key to return to weighing.
