- 71 -
• Then set the rest of the parameters
Printout number – 1
Prn. 1 start – 1
Prn. 1 stop – 10
Draw. 67. Declaration of range of printout
− After setting all the corresponding parameters, return to weighing mode (save the
parameters).
Now you can connect the balance with the printer (a cable diagram in the users’
manual). Check the setting of transmission parameters both in the balance and in the
printer. They should be the same. Place a load on the weight pan and after stabilizing
press PRINT. The designed printout will be sent to the printer and three identical
labels will be printed out.
The printout apperance
Draw. 68. Printed label
