CITROEN AMI 2021 - Electric Motor; Dimensions

34
Technical data
Electric motor
Version AMI AMI
CARGO
Model code:
9A...
Z2CA Z2CA
Weights
Unladen weight,
battery included (kg)
471 478
Maximum loading
weight with driver
(kg)
150 140
Gross vehicle weight
(kg)
700 700
Tyres 155/65R14
Electric motor
Technology Synchronous with
permanent magnets
Nominal power: EC
standard (kW)/(hp)
6/8.2
Max. power: EC
standard (kW)/(hp)
9.4/12.6
Traction battery
Technology Lithium-Ion
Installed capacity
(kWh)
5.5
Domestic charging
Version AMI AMI
CARGO
Model code:
9A...
Z2CA Z2CA
Alternating current
voltage (Vac)
230 (single-phase)
Rating (A) 16
Charging cable
length (m)
3
Charging time (hr) 3 hrs for 80%
Driving range (miles/
km)
46/75
Dimensions (mm)
These dimensions have been measured on an
unladen vehicle.
