INJECTION
AIR SUPPLY CIRCUIT SPECIFICATION
Engines : 8HX - 8HW
WARNING: After each removal, replace the seals of components that have been removed, lubricating the new seals when refitting.
Lower integrated air inlet distributor.
Upper integrated air inlet distributor.
Oil trap fixing screw.
Diesel fuel filter support fixing screw.
Diesel fuel filter support fixing screw.
Integrated air distributor fixing screw.
1 à 8
9 à 10
11
12 à 13
1 ± 0.1
1 ± 0.1
0.5
1 ± 0.1
13
14
15
16
17
0.5
0.75
Description
Tighten in
sequence
m.daN.
Air filter housing fixing screw.
Air filter cover fixing screw.
Air inlet duct fixing screw.
Resonator on turbocharger fixing screw.
Resonator on oil trap fixing screw.
Description
Tighten in
sequence
m.daN.
B1HP1JPD B1HP1JQD
