AL 4 AUTOMATIC GEARBOX
Engine : KFV
Tightening torques: (m.daN).
(1) Fixing of electrovalve for modulation of flow of oil into
the exchange (EPDE) : 1 ± 0.2
(2) Fixing of oil heat exchanger : 5 ± 1
(3) Fixing of gearbox input speed sensor : 1 ± 0.2
(4) Fixing of oil overflow and drainage (X = 81 mm). : 4 ± 0.2
(5) Oil top-up plug : 2.4 ± 0.4
(6) Fixing of oil pressure sensor : 0.8 ± 0.1
B2CP3H2D
B2CP3H3D
155
CLUTCH
GEARBOX
DRIVESHAFTS
