SPECIAL FEATURES : TIGHTENING TORQUES (m.daN)
Flywheel - Clutch
Engines 8HY-8HV
Flywheel 1.7 ± 0.2
Clutch mechanism 2 ± 0.2
Lubrication circuit
Oil pump assembly 0.9 ± 0.1
Oil/coolant heat exchanger 1 ± 0.1
Turbocharger lubrication pipe 2.2 ± 0.2
Injection circuit
Injector fixing flange nut
Tightening 0.4 ± 0.1
Angular tightening 65°±5°
Unions on fuel high pressure common injection rail
2.3 ± 0.2
Fuel high pressure pump
Union on diesel injector
Fuel high pressure pump pinion 5 ± 0.5
Union on fuel high pressure pump 2.3 ± 0.2
Cooling circuit
Coolant pump 1 ± 0.2±
ENGINE
