CITROEN C5 2013 - Changing Front Foglamps; Changing Side Repeaters

171
11
P R A C T I C A L I N F O R M A T I O N
Changing front foglamps
 Remove the fi xing screw of cover
A using a torx tool, tip the cover
over and remove.
 Remove the fi xing screw of
lamp B using a torx tool and pull
the headlamp unit to remove it
from the bumper.
The side repeater is sealed.
If the bulb is faulty, replace the side
repeater.
Consult a CITROËN dealer.
Changing side repeaters
 Disconnect the connector D .
 Remove the bulb by performing
a quarter of a turn.
 Replace the bulb.
 Connect the connector D .
 Replace the headlamp unit in the
bumper.
 Screw the headlamp unit in.
 Position the cover using its
guides and screw in.
Bulbs: H8
When refi tting, take care not to
trap the electrical cables.
