CITROEN C5 2013 - Dimensions (in MM); Exterior (Saloon)

To Next Page

To Previous Page

202

T E C H N I C A L D A T A

* Without roof bars.

DIMENSIONS (IN MM)

Exterior (Saloon)

A 2 815

B 1 054

C 910

D 4 779

E 1 586

F 2 096

G 1 557

H 1 860

I * 1 451
