CKD AX1000T Series User Manual

17
AX4000T
Series
Dimensions
AX4045T

AX4045T-EB
With electromagnetic brake
Refer to the left drawings for options.

37.5°
P.
C.D. 122
Recommended value for
lead wire relief dimensions
4-M6 depth 12 (straight)
(Screw valid length 9)
For mounting dial plate
4-M6 depth 12 (straight)
P.
C.D. 160
Φ180±2
Φ140h7
P.
C.D.160
(9.5)
28.5
4-M6 depth 12 (straight)
(Screw valid length 9)
For mounting dial plate
4-M6 depth 12 (straight)
P.
C.D. 160
Φ180±2
Φ140h7
P.
C.D.160
(9.5)
28.5
Lead wire
300 from outlet
5°
3-M5 (straight)
For electromagnetic brake manual release
45°
5°
Φ140
R8
45.2
10
Electromagnetic brake
(Protection element attached)
C10
200 150
Φ6H7 depth 8 (option)
4-M6 depth 12 (straight)
For installing optional electromagnetic brake
P.
C.D.54
45°
150
200
Φ6H7 depth 8 (option)
Not available if the optional base is installed
3-M6 depth 12 (straight)
optional electromagnetic brake
For mounting
P.C.D.125
Rotating section
(Including hollow section)
Φ170
Φ100h7
139.5
5
Φ70
115
Φ25
115
5
Φ100h7
Φ170
Rotating section
(Including hollow section)
129.5
Φ45
Φ44
65 12
88
4-Φ7
Mounting base (option)
83 83
32 32
(11)
45°
115
0.06
A
A
B
0.06
B
80
80
Cable bending range (Downward bending range is 125)
145
(Note): Fix the end of the cable
sheath when bending repeatedly.
27.3
25.6
27.3 25.6
Note 1) The origin of the actuator may differ from the dimensions shown above.
Origin can be configured randomly using the origin offset function.
