18 00 0294 514 0 - RHB QUADRANT 3400 - 03/10
Introduction
Torque settings
81213
14055
Tightening torques for hydraulic screw fittings and air conditioner fittings with a sealing cone
and O-ring DIN 3865
Outside tube diameter
in mm
Tightening torque
(light series)
in Nm
Tightening torque
(heavy series)
in Nm
61015
81525
10 25 35
12 35 50
15 50 -
16 - 80
18 80 -
20 - 110
22 110 -
25 - 160
28 160 -
30 - 210
35 210 -
38 - 320
42 320 -
