Claas QUADRANT 3400 User Manual

00 0294 514 0 - RHB QUADRANT 3400 - 03/10 19
Introduction
Torque settings
81213
52260
Tightening torques for hydraulic male connector DIN 3901
Shape B with sealing edge
(cutting edge)
Shape E with flexible sealing lining
Shape F with O-ring
Dimensions Tightening torque
(light series)
In Nm
Tightening torque
(heavy series)
In Nm
Tightening torque
(light series)
In Nm
Tightening torque
(heavy series)
In Nm
M8 x 1--9-
M10 x 1 18 - 11 -
M12 x 1.530351515
M14x1.545552525
M16x1.560703535
M18 x 1.5 70 110 50 50
M20 x 1.5 - 140 - 55
M22 x 1.5 140 170 80 80
M26 x 1.5 180 220 110 110
M27 x 2 190 250 110 160
M33 x 2 300 300 160 210
M42 x 2 500 550 210 320
M48 x 2 550 600 320 420
G1/8A 20 25 - -
G1/4A 35 40 - -
G3/8A 70 90 - -
G 1/2 A 100 150 - -
G 3/4 A 180 270 - -
G 1 A 250 350 - -
G 1 1/4 A 450 500 - -
G 1 1/2 A 550 600 - -
7/16 - 20 (11.1 mm) - - 15 20
1/2-20 (UNF) - - 20 25
9/16 - 18 (14.3 mm) - - 30 30
3/4 - 16 (19.1 mm) - - 35 60
7/8 - 14 (22.2 mm) - - 70 90
11/16-12 (27mm) - - 85 100
