Claas QUADRANT 3400 - Torque Settings - Hydraulic Connectors Continued; Hydraulic Connectors with Sealing and O-ring

20 00 0294 514 0 - RHB QUADRANT 3400 - 03/10
Introduction
Torque settings
81213
15/16-12
(33.3 mm)
- - 150 170
15/8-12 (UNF) - - 250 300
17/8-12 (UNF) - - 300 350
2 - 12 (UNF) - - 350 400
Shape B with sealing edge
(cutting edge)
Shape E with flexible sealing lining
Shape F with O-ring
Dimensions Tightening torque
(light series)
In Nm
Tightening torque
(heavy series)
In Nm
Tightening torque
(light series)
In Nm
Tightening torque
(heavy series)
In Nm
