Claas QUADRANT 3400 User Manual

00 0294 514 0 - RHB QUADRANT 3400 - 03/10 21
Introduction
Torque settings
81213
52288
Tightening torques for direction-adjustable hydraulic male connectors
ISO 6149-2 / ISO 11926-2 (3)
Dimensions Tightening torque
(extra light series)
In Nm
Tightening torque
(light series)
In Nm
Tightening torque
(heavy series)
In Nm
M8 x 1 10 - -
M10 x 1 20 15 -
M12 x 1.5 - 25 35
M14 x 1.5 - 35 45
M16 x 1.5 - 40 55
M18 x 1.5 - 45 90
M20 x 1.5 - - 140
M22 x 1.5 - 60 170
M26 x 1.5 - 100 190
M27 x 2 - 100 190
M33 x 2 - 160 310
M42 x 2 - 210 330
M48 x 2 - 260 420
-
7/16 - 20 UNF - 15 20
1/2 - 20 UNF - 30 40
9/16 - 18 UNF - 35 45
3/4 - 16 UNF - 55 60
7/8 - 14 UNF - 80 90
11/16-18 UNF - 100 100
15/16-12 UNF - 150 170
15/8-12 UNF - 290 340
17/8-12 UNF - 325 415
2 - 12 (UNF) - 350 450
