Claas QUADRANT 3400 User Manual

22 00 0294 514 0 - RHB QUADRANT 3400 - 03/10
Introduction
Torque settings
81213
52295
Tightening torques for hydraulic swivelling screw fittings
Dimensions Tightening torque
(light series)
in Nm
Tightening torque
(heavy series)
in Nm
M10 x 1 20 30
M12 x 1.5 35 40
M14 x 1.5 45 50
M16 x 1.5 60 70
M18 x 1.5 75 80
M20 x 1.5 - 100
M22 x 1.5 125 130
M26 x 1.5 130 -
M27 x 2 130 140
M33 x 2 300 300
M42 x 2 500 500
M48 x 2 600 600
G1/8A 20 -
G1/4A 40 40
G3/8A 65 70
G1/2A 90 100
G 3/4 A 130 130
G 1 A 270 380
G 1 1/4 A 500 600
G 1 1/2 A 600 700
