Claas ROLLANT 250 Repair Manual

2.1.2
RHB ROLLANT 250 / 250 RC - 298 332.0
Drives
Force one bushing in the double yoke (H) through on
one side, using a tube, far enough for the grooved
yoke to make contact.
Important!
The tube must be 1 mm smaller than the bush-
ing diameter.
(Fig. 5)
Clamp the forced-out bushing (G) in a vise and drive it
out by light blows against the double yoke.
(Fig. 6)
Push the centre cross assembly (K) downward to the
stop, at the same time pushing the second bushing a
little out of the double yoke.
(Fig. 7)
Remove centre cross assembly (K) from the double
yoke (H) and the bushing.
(Fig. 8)
H
F
5
G
6
K
7
K
H
8
