5
Instructions for user - 9120-25530 - CEX9 - 801039 - November 2012 v1.00
Model CEX 9 ELECTRONIC MPS
®
Part no.
27900
Rated capacity / rated current
6,0 / 9,6 kW (27,3 / 40 A)
Chosen capacity @ 230 V 6,6 kW (28,7 A) 8,8 kW (38,3 A)
Electrical connection 1/N/PE 220..240 V AC
Min. required cable size
3)
See note 3)
Hot water (l/min) max. at t = 25 K 3,8 5,0
Rated volume 0,3 l
Type Pressure type 1 MPa (10 bar)
Heating system bare wire heating system IES
®
Required spec. water
resistance @ 15 °C
Spec. electrical conductivity
1100 cm
90,9 mS/m
Inlet temperature 70 °C
Flow rate to switch on – max. flow rate 2,0 – 5,0 l/min
1)
Pressure loss
20 kPa / at 2,5 l/min
130 kPa / at 9,0 l/min
2)
Temperature range 20 °C – 50 °C
Water connection G ½“
Weight
(when filled w. water)
2,7 kg
VDE class of protection I
Type of protection / safety
IP25
1) Flow rate limited to achieve optimum temperature rise
2) Without flow regulator
3) The cross sectional area of the connection cable must be in accordance with the power rating of the appliance and the specific requirements
of AS/NZS 3000.
4. Technical specifications
5. Dimensions
Dimensions in mm
WMKA30016
AS 3498
