ARX8570z 15
Tape Operations
Notes:
If the FILP DOWN PANEL does not open fully, gen-
tly open with your hand.
The radio mode is selected automatically 4 seconds
after Eject button
&
is pressed.
If the auto antenna terminal for this unit is connected,
the antenna is extended automatically. If you are in
a location where the antenna may strike something,
press FNC button
3
to switch the mode.
Switching to the other side of the tape
Press PROG button @ to change tape direction
and playback.
The tape mechanism automatically reverses di-
rection and engage playback at the end of the tape
(auto reverse).
Fast-forwarding/rewinding
FF(fast-forward):
Press the right side of SEARCH button $.
REW(rewind):
Press the left side of SEARCH button $.
Canceling FF/REW:
Press Play/pause button 2.
When the end of the tape is reached with FF/REW,
the mechanism automatically reverses tape direc-
tion and resumes playback.
If you select another mode during FF/REW, it is
selected with FF/REW continued.
The mechanism automatically makes FF/REW
stop when the end of the tape is reached.
This function is called “monitor mode”.
APC (Auto Program Control) function
The APC function allows the tape to skip forward
to the beginning of the next track or rewind to
the start of the current track.
Skipping forward to the next track (“APC-
FF”)
During tape playback, press the right side of
SEARCH button $ twice to fast-forward to the
next track. The next track starts playing.
Skipping backwards to the start of the cur-
rent track (“APC-REW”)
During tape playback, press the left side of
SEARCH button $ twice to rewind to the start
of the current track. The current track plays from
the beginning.
Canceling FF/REW APC to resume playback
Press Play/pause button 2.
If you select another mode during APC mode, it is
selected with APC mode continued.
The mechanism automatically makes APC mode
stop when it finds the next track (in APC-FF) or
the start of the current track (in APC-REW). This
function is called “monitor mode”.
Dolby noise reduction system
The Dolby noise reduction system increases the
volume level of high frequency sounds during
recording and sets it back to their original level
during play. This system reduces hissing noise
which is typical of cassette tapes.
Dolby noise reduction manufactured under license
from Dolby Laboratories Licensing Corporation.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories Licensing Corporation.
1. Press DOLBY NR button 7 to select Dolby
noise reduction. Each time you press DOLBY
NR button 7, the Dolby type changes in the
following order:
DOLBY B NR ONDOLBY C NR ONDOLBY
NR OFFDOLBY B NR ON....
2. When DOLBY B NR ON is selected, “DOLBY
B NR appears in the display. On the contrary,
when DOLBY C NR ON is selected, “DOLBY
C NR appears in the display.
Intro tape scan
The intro tape scan allows the first 10 seconds
of all the tracks on the tape to be played.
This function continues automatically until it is
canceled.
1. Press SCN button 5 to start the intro tape
scan.SCN” lights in the display.
2. To cancel the intro tape scan, press SCN but-
ton 5 again. SCN” goes off from the display
and the current track continues to play.
When the end of the tape is reached during the
intro tape scan, the tape mechanism automatically
reverses direction and continues the intro tape
scan.
If you select another mode during the intro tape
scan, the mechanism automatically makes the intro
tape scan stop when it finds the next track (APC
function).

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Clarion ARX8570z and is the answer not in the manual?

Clarion ARX8570z Specifications

FM Tuner IconFM Tuner
frequency range87.9 MHz to 107.9 MHz
usable sensitivity11 dBf
50dB quieting sensitivity17 dBf
alternate channel selectivity75 dB
stereo separation (1 kHz)35 dB
frequency response (±3 dB)30 Hz to 15 kHz
AM Tuner IconAM Tuner
frequency range530 kHz to 1710 kHz
usable sensitivity25 µV
Tape Deck IconTape Deck
wow & flutter (WRMS)0.06%
channel separation (1 kHz)45 dB
frequency response (±3 dB, 120 µs, normal)30 Hz to 18 kHz
frequency response (±3 dB, 70 µs, CrO2, FeCr, Metal)30 Hz to 20 kHz
signal to noise ratio, 70 µs, Dolby NR OFF58 dB
signal to noise ratio, 70 µs, Dolby B NR67 dB
signal to noise ratio, 70 µs, Dolby C NR74 dB
Audio IconAudio
maximum power output180 W (45 W × 4 ch) (EIAJ)
continuous average power output17 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1% THD
bass control action (30 Hz)±15 dB
treble control action (10 kHz)±10 dB
line output level (0VU tape)1.6 V
General IconGeneral
power supply voltage14.4 V DC (10.8 to 15.6 V allowable), negative ground
current consumptionLess than 15 A
speaker impedance4 Ω (4 Ω to 8 Ω allowable)
weight / source unit3.52 lb. (1.6 kg)
weight / remote control unit1 oz. (30 g) (including battery)
dimensions / source unit7" (Width) × 2" (Height) × 6-1/8" (Depth) [178 (W) × 50 (H) × 155 (D) mm]
dimensions / remote control unit1-3/4" (Width) × 4-5/16" (Height) × 1-1/8" (Depth) [44 (W) × 110 (H) × 27 (D) mm]
