Clarion ARX8570z User Manual

2 ARX8570z ARX8570z 89
Contents
1. FEATURES ..................................................................................................................................... 3
2. PRECAUTIONS .............................................................................................................................. 3
Handling Cassette Tapes ................................................................................................................ 4
Flip Down Panel .............................................................................................................................. 4
3. CONTROLS .................................................................................................................................... 5
4. NOMENCLATURE .......................................................................................................................... 6
Names of Buttons............................................................................................................................ 6
Display Items................................................................................................................................... 6
5. DCP ................................................................................................................................................. 7
6. REMOTE CONTROL ...................................................................................................................... 8
Inserting the Batteries ..................................................................................................................... 8
Functions of Remote Control Unit Buttons ..................................................................................... 9
7. OPERATIONS............................................................................................................................... 10
Basic Operations ........................................................................................................................... 10
Radio Operations .......................................................................................................................... 13
Tape Operations ............................................................................................................................ 14
Other Handy Functions ................................................................................................................. 16
8. OPERATIONS OF ACCESSORIES ............................................................................................. 19
CD Changer Operations ............................................................................................................... 19
MD Changer Operations ............................................................................................................... 21
TV Operations ............................................................................................................................... 22
DSP Operations ............................................................................................................................ 24
9. TROUBLESHOOTING.................................................................................................................. 28
10. ERROR DISPLAYS....................................................................................................................... 29
11. SPECIFICATIONS ........................................................................................................................ 30
Thank you for purchasing the Clarion ARX8570z.
∗ Please read this owner’s manual in its entirety before operating this equipment.
∗ After reading this manual, be sure to keep it in a handy place (e.g., glove compartment).
∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.
∗ This manual includes the operating procedures of the CD changer, MD changer, TV tuner and digital
sound processor (DSP) connected via the CeNET cable. The CD changer, MD changer, TV tuner
and DSP have their own manuals, but no explanations for operating them are described.
11. ESPECIFICACIONES
Sintonizador de FM
Gama de frecuencias:
87,9 a 107,9 MHz
Sensibilidad útil:
11 dBf
Sensibilidad a 50 dB de silenciamiento:
17 dBf
Selectividad de canal alternativo:
75 dB
Separación entre canales (1 kHz):
35 dB
Respuesta en frecuencia (±3 dB):
30 Hz a 15 kHz
Sintonizador de AM
Gama de frecuencias:
530 a 1710 kHz
Sensibilidad útil:
25 µ V
Reproductor de casetes
Fluctuación y trémolo (ponderación eficaz):
0,06%
Separación entre canales (1 kHz):
45 dB
Respuesta en frecuencia (±3 dB)
120 µ s (normal):
30 Hz a 18 kHz
70 µ s (CrO2, FeCr, Metal):
30 Hz a 20 kHz
Relación señal-ruido, 70 µ s (CrO2, FeCr, Metal)
Dolby NR OFF:
58 dB
Dolby B NR:
67 dB
Dolby C NR:
74 dB
Audio
Salida máxima de potencia:
180 W (45 W × 4 canales) (EIAJ)
Salida media continua de potencia:
17 W × 4, con 4 Ω, de 20 Hz a 20 kHz, 1% de
distorsión armónica total
Acción de control de graves (30 Hz):
±15 dB
Acción de control de agudos (10 kHz):
±10 dB
Nivel de salida de línea (cinta 0VU):
1,6 V
Generales
Tensión de alimentación:
14,4 V CC (permisible de 10,8 a 15,6 V),
negativo a masa
Consumo de corriente:
Menos de 15 A
Impedancia de los altavoces:
4 Ω (permisible de 4 a 8 Ω)
Peso / Unidad fuente:
3,52 lb. (1,6 kg)
Peso / Controlador remoto:
1 oz. (30 g) (incluyendo la pila)
Dimensiones / Unidad fuente:
7 " (An) × 2 " (Al) × 6-1/8 " (Prf)
[178 (An) × 50 (Al) × 155 (Prf) mm]
Dimensiones / Controlador remoto:
1-3/4 " (An) × 4-5/16 " (Al) × 1-1/8 " (Prf)
[44 (An) × 110 (Al) × 27 (Prf) mm]
Notas:
• Las especificaciones están de acuerdo con las normas de la EIA.
• Las especificaciones y el diseño están sujetos a cambio sin previo aviso por motivo de mejoras.

Clarion ARX8570z Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	11 dBf
50dB quieting sensitivity	17 dBf
alternate channel selectivity	75 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

Tape Deck

wow & flutter (WRMS)	0.06%
channel separation (1 kHz)	45 dB
frequency response (±3 dB, 120 µs, normal)	30 Hz to 18 kHz
frequency response (±3 dB, 70 µs, CrO2, FeCr, Metal)	30 Hz to 20 kHz
signal to noise ratio, 70 µs, Dolby NR OFF	58 dB
signal to noise ratio, 70 µs, Dolby B NR	67 dB
signal to noise ratio, 70 µs, Dolby C NR	74 dB

Audio

maximum power output	180 W (45 W × 4 ch) (EIAJ)
continuous average power output	17 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1% THD
bass control action (30 Hz)	±15 dB
treble control action (10 kHz)	±10 dB
line output level (0VU tape)	1.6 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable), negative ground
current consumption	Less than 15 A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	3.52 lb. (1.6 kg)
weight / remote control unit	1 oz. (30 g) (including battery)
dimensions / source unit	7" (Width) × 2" (Height) × 6-1/8" (Depth) [178 (W) × 50 (H) × 155 (D) mm]
dimensions / remote control unit	1-3/4" (Width) × 4-5/16" (Height) × 1-1/8" (Depth) [44 (W) × 110 (H) × 27 (D) mm]
