Clarion ARX8570z User Manual

30 ARX8570z
11. SPECIFICATIONS
FM Tuner
Frequency Range:
87.9 MHz to 107.9 MHz
Usable Sensitivity:
11 dBf
50dB Quieting Sensitivity:
17 dBf
Alternate Channel Selectivity:
75 dB
Stereo Separation (1 kHz):
35 dB
Frequency Response (±3 dB):
30 Hz to 15 kHz
AM Tuner
Frequency Range:
530 kHz to 1710 kHz
Usable Sensitivity:
25 µ V
Tape Deck
Wow & Flutter (WRMS):
0.06%
Channel Separation (1 kHz):
45 dB
Frequency Response (±3 dB):
120 µ s (normal):
30 Hz to 18 kHz
70 µ s (CrO2, FeCr, Metal):
30 Hz to 20 kHz
Signal to Noise Ratio, 70 µ s (CrO2, FeCr, Metal)
Dolby NR OFF:
58 dB
Dolby B NR:
67 dB
Dolby C NR:
74 dB
Notes:
• Specifications comply with EIA Standards.
• Specifications and design are subject to change without notice for further improvement.
Audio
Maximum Power Output:
180 W (45 W × 4 ch) (EIAJ)
Continuous Average Power Output:
17 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1%THD
Bass Control Action (30 Hz):
±15 dB
Treble Control Action (10 kHz):
±10 dB
Line Output Level (0VU tape):
1.6 V
General
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Current Consumption:
Less than 15 A
Speaker Impedance:
4 Ω (4 Ω to 8 Ω allowable)
Weight / Source unit:
3.52 lb. (1.6 kg)
Weight / Remote control unit:
1 oz. (30 g) (including battery)
Dimensions / Source unit:
7 " (Width) × 2 " (Height) × 6 - 1/8 " (Depth)
[178 (W) × 50 (H) × 155 (D) mm]
Dimensions / Remote control unit:
1-3/4 " (Width) × 4-5/16 " (Height) × 1 - 1/8 " (Depth)
[44 (W) × 110 (H) × 27 (D) mm]

Clarion ARX8570z Specifications

FM Tuner

frequency range	87.9 MHz to 107.9 MHz
usable sensitivity	11 dBf
50dB quieting sensitivity	17 dBf
alternate channel selectivity	75 dB
stereo separation (1 kHz)	35 dB
frequency response (±3 dB)	30 Hz to 15 kHz

AM Tuner

frequency range	530 kHz to 1710 kHz
usable sensitivity	25 µV

Tape Deck

wow & flutter (WRMS)	0.06%
channel separation (1 kHz)	45 dB
frequency response (±3 dB, 120 µs, normal)	30 Hz to 18 kHz
frequency response (±3 dB, 70 µs, CrO2, FeCr, Metal)	30 Hz to 20 kHz
signal to noise ratio, 70 µs, Dolby NR OFF	58 dB
signal to noise ratio, 70 µs, Dolby B NR	67 dB
signal to noise ratio, 70 µs, Dolby C NR	74 dB

Audio

maximum power output	180 W (45 W × 4 ch) (EIAJ)
continuous average power output	17 W × 4, into 4 Ω, 20 Hz to 20 kHz, 1% THD
bass control action (30 Hz)	±15 dB
treble control action (10 kHz)	±10 dB
line output level (0VU tape)	1.6 V

General

power supply voltage	14.4 V DC (10.8 to 15.6 V allowable), negative ground
current consumption	Less than 15 A
speaker impedance	4 Ω (4 Ω to 8 Ω allowable)
weight / source unit	3.52 lb. (1.6 kg)
weight / remote control unit	1 oz. (30 g) (including battery)
dimensions / source unit	7" (Width) × 2" (Height) × 6-1/8" (Depth) [178 (W) × 50 (H) × 155 (D) mm]
dimensions / remote control unit	1-3/4" (Width) × 4-5/16" (Height) × 1-1/8" (Depth) [44 (W) × 110 (H) × 27 (D) mm]
