ARX8570z 11
∗ Once selected, the preferred display becomes
the display default. When a function adjustment
such as volume is made, the screen will mo-
mentarily switch to that function’s display, then
revert back to the preferred display several
seconds after the adjustment.
∗ When you have entered a title in a CD, it ap-
pears in the sub display. If you have not en-
tered a title, “NO-TTL” appears in the title dis-
play instead. For information on how to enter
a title, refer to the subsection “Entering titles”
in the “Other Handy Functions”.
Setting the Z-enhancer
This unit comes with 3 types of sound tone effects
stored in memory. Select the one you prefer.
∗ The factory default setting is “Z-EHCR OFF”.
Each time you press Z-EHCR button 8, the tone
effect changes in the following order:
“Z-ENHANCER 1” ➜ “Z-ENHANCER 2” ➜ “Z-
ENHANCER 3” ➜ “Z-EHCR OFF” ➜ “Z-EN-
HANCER 1”...
• Z-ENHANCER 1: bass emphasized
• Z-ENHANCER 2: treble emphasized
• Z-ENHANCER 3: bass and treble emphasized
• Z-EHCR OFF : no sound effect
Adjusting the tone
Press A-M button # and select the item to ad-
just. Each time you press A-M button #, the item
changes in the following order:
●
When the Z-enhancer and tone bypass are off
“NON-FAD VOL” ➜ “TONE BYPASS” ➜
“BASS” ➜ “TREBLE” ➜ “BALANCE” ➜
“FADER” ➜ Function mode...
● When Z-enhancer 1, 2 or 3 is set
“NON-FAD VOL” ➜ “Z-EHCR” ➜ “BALANCE”
➜ “FADER” ➜ Function mode...
Note:
•
When the separately-sold digital sound processor
(DPH7500z) is used, the tone bypass, bass and
treble tone adjustments cannot be selected. To
adjust the tone, refer to the chapter “DSP Opera-
tions”.
Adjusting the non-fader output volume
You can adjust the volume output from the unit’s
non-fader output terminal.
1.
Press A-M button # and select “NON-FAD VOL”.
2.
Turning the Rotary knob % clockwise increases
the output volume; turning it counterclockwise
decreases the output volume.
∗
The factory default setting is “4”. (Setting range: 0 to 7)
Basic Operations
3. When the adjustment is complete, press A-M
button # several times until the function mode
is reached.
Setting tone bypass
The tone bypass disables the tone (bass and
treble) functions and cuts the noise generated
when the tone functions are on.
1. Press A-M button # and select “TONE BY-
PASS”.
2. Turning the Rotary knob % clockwise sets the
tone bypass to “YES” (ON); turning it coun-
terclockwise sets the tone bypass to “NO”
(OFF).
∗ The factory default setting is “NO” (OFF).
∗ If the setting is “YES” (ON), the bass and treble
adjustments cannot be made.
3. When the adjustment is complete, press A-M
button # several times until the function mode
is reached.
Note:
• If you set the Z-ENHANCER function to ON (1 to
3), you cannot set the tone bypass.
Adjusting the bass
1. Press A-M button # and select “BASS”.
2. Turning the Rotary knob % clockwise empha-
sizes the bass; turning it counterclockwise
attenuates the bass.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +6)
∗ The bass cannot be adjusted if the tone by-
pass setting is “YES” (ON).
3. When the adjustment is complete, press A-M
button # several times until the function mode
is reached.
Adjusting the treble
1. Press A-M button # and select “TREBLE”.
2. Turning the Rotary knob % clockwise empha-
sizes the treble; turning it counterclockwise
attenuates the treble.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +6)
∗ The treble cannot be adjusted if the tone by-
pass setting is “YES” (ON).
3. When the adjustment is complete, press A-M
button # several times until the function mode
is reached.
