Clarion CMM-20 User Manual

4
AUX
CMR-10
CMR-20
AM FM
USB
1A
USB
ANT
AUX-IN
REMOTE
Z1 SPKR OUT
Z2 SPKR OUT
Z1 L+ (WH)
Z1 L− (WH/BK)
Z1 R+ (GY)
Z1 R− (GY/BK)
Z2 L+ (GN)
Z2 L− (GN/BK)
Z2 R+ (VI)
ILLUMINATION (OR) +
GROUND (BK) −
AMP TURN-ON (BL) +
Z2 R− (VI/BK)
POWER
ZONE 2 / SUB
+12V
(10 - 14.4V DC)
15A
+12V DC (RD) +
GENERAL CONNECTIONS
