Clarion CZ109 Service Manual

-8-
CZ109/CZ109A
Switch PWB(B2) section
REF No.
PART No. DESCRIPTION
REF No.
PART No. DESCRIPTION
REF No.
PART No. DESCRIPTION
C701 043-1841-90 0.047uF J702 075-9021-51 5P R722 119-5621-15
1/10W 5.6k ohm
C702 043-1841-90 0.047uF LCD701 379-1426-41
INDICATOR(LCD)
R724 119-2221-15
1/10W 2.2k ohm
C703 043-1841-90 0.047uF P701 076-0502-55 5P R725 119-1021-15
1/10W 1k ohm
C704 043-1800-90 1000pF Q713 125-2027-92 DTC124EUA R726 119-5621-15
1/10W 5.6k ohm
C705 042-0423-97 16V 10uF Q713 125-2041-93
RT1N241M
S701 013-6312-50 SWITCH
C706 042-0423-97 16V 10uF Q714 125-2027-92 DTC124EUA S702 013-6312-50 SWITCH
C707 043-1841-90 0.047uF Q714 125-2041-93
RT1N241M
S703 013-6312-50 SWITCH
D702 001-4907-90 PG05GBUSU R701 119-3311-15
1/10W 330 ohm
S704 013-6312-50 SWITCH
D705 001-4301-29 HZU5.1B2 R702 119-3931-15
1/10W 39k ohm
S705 013-6312-50 SWITCH
D706 001-4301-29 HZU5.1B2 R703 119-1041-15
1/10W 100k ohm
S706 013-6312-50 SWITCH
D707 001-4907-90 PG05GBUSU R704 119-3921-15
1/10W 3.9k ohm
S707 013-6312-50 SWITCH
D708 001-4907-90 PG05GBUSU R705 119-2221-15
1/10W 2.2k ohm
S709 013-6312-50 SWITCH
D711 001-7097-90 DIODE R706 119-1021-15
1/10W 1k ohm
S710 013-6312-50 SWITCH
D712 001-7097-90 DIODE R707 119-1021-15
1/10W 1k ohm
S711 013-6312-50 SWITCH
D713 001-7097-90 DIODE R708 119-1011-15 1/10W 100 ohm S713 013-6312-50 SWITCH
D714 001-7097-90 DIODE R709 119-4721-15
1/10W 4.7k ohm
S714 013-6312-50 SWITCH
D715 001-7114-91 DIODE R713 119-6811-15
1/10W 680 ohm
S715 013-6312-50 SWITCH
D716 001-7114-91 DIODE R714 119-6811-15
1/10W 680 ohm
S716 013-6312-50 SWITCH
D717 001-4301-29 HZU5.1B2 R715 119-1811-15
1/10W 180 ohm
S717 013-6312-50 SWITCH
D718 001-4301-41 HZU7.5B2 R716 119-1811-15
1/10W 180 ohm
S718 016-9901-02
VR W/SHAFT
D720 001-4301-51 HZU10B3 R717 119-1811-15
1/10W 180 ohm PWB 039-3388-00 PWB(WITHOUT
IC701 051-6095-00 LC75857 R718 119-1811-15
1/10W 180 ohm COMPONENT)
IR701 060-4021-00 GPIUX51 R719 119-6811-15
1/10W 680 ohm
J701 076-0615-50 12P R720 119-6811-15
1/10W 680 ohm
REF No.
PART No. DESCRIPTION
REF No.
PART No. DESCRIPTION
REF No.
PART No. DESCRIPTION
Q801 190-2060-00 2SA2060 R500 116-4721-15 1/4WS 4.7K ohm R821 119-1011-15 1/16W 100 ohm
Q802 101-0941-00 2SB941 R501 119-4731-15 1/10W 47K ohm R825 119-3921-15 1/16W 3.9K ohm
R108 033-1031-15 1/16W 10K ohm R502 033-4721-15 1/16W 4.7K ohm R826 119-3921-15 1/16W 3.9K ohm
R154 116-1521-15 1/4WS 1.5K ohm R503 033-4731-15 1/16W 47K ohm R827 119-3921-15 1/16W 3.9K ohm
R156 119-1241-15 1/16W 120K ohm R504 033-4721-15 1/16W 4.7K ohm R828 033-2731-15 1/16W 27K ohm
R159 116-1221-15 1/4WS 1.2K ohm R505 033-1031-15 1/16W 10K ohm R829 119-1021-15 1/10W 1K ohm
R200 119-1031-15 1/16W 10K ohm R506 033-1041-15 1/16W 100K ohm R830 033-1011-15 1 /16W 100 ohm
R201 119-5631-15 1/16W 56K ohm R507 033-6831-15 1/16W 68K ohm R831 033-2221-15 1/16W 2.2K ohm
R207 119-0000-05 1/10W 0 ohm JW R512 119-0000-05 1/10W 0 ohm JW R832 033-2221-15 1/16W 2.2K ohm
R209 119-2711-15 1/16W 270 ohm R513 033-4731-15 1/16W 47K ohm R833 033-2221-15 1/16W 2.2K ohm
R212 119-0000-05 1/10W 0 ohm JW R514 033-4731-15 1/16W 47K ohm R834 119-2201-15 1/16W 22 ohm
R223 033-2221-15 1/16W 2.2K ohm R515 119-1841-15 1/10W 180K ohm R835 033-3321-15 1/16W 3.3K ohm
R224 033-2221-15 1/16W 2.2K ohm R516 033-4731-15 1/16W 47K ohm R836 033-1511-15 1/16W 150 ohm
R225 033-1031-15 1/16W 10K ohm R521 033-5641-15 1/16W 560K ohm R837 033-2231-15 1 /16W 22K ohm
R230 033-1021-15 1/16W 1K ohm R526 033-1031-15 1/16W 10K ohm R839 119-4701-15 1/16W 47 ohm
R233 119-4741-15 1/16W 470K ohm R527 033-1031-15 1/16W 10K ohm R840 119-3301-15 1/16W 33 ohm
R236 119-3311-15 1/16W 330 ohm R528 033-5621-15 1/16W 5.6K ohm R841 119-1511-15 1/16W 150 ohm
R313 033-2711-15 1/16W 270 ohm R529 119-4721-15 1/16W 4.7K ohm R842 119-1511-15 1/16W 150 ohm
R314 033-2711-15 1/16W 270 ohm R532 119-4721-15 1/16W 4.7K ohm R845 033-0000-05 0.5A 0 ohm
R315 033-2711-15 1/16W 270 ohm R530 033-1031-15 1/16W 10K ohm R846 033-0000-05 0.5A 0 ohm
R316 033-2711-15 1/16W 270 ohm R531 033-4721-15 1/16W 4.7K ohm R847 033-0000-05 0.5A 0 ohm
R317 119-3311-15 1/16W 330 ohm R533 033-1041-15 1/16W 100K ohm R848 033-0000-05 0.5A 0 ohm
R325 032-0140-89 1/ 10W 47K ohm F R534 033-1031-15 1/16W 10K ohm R849 033-1031-15 1/16W 10K ohm
R326 032-0140-89 1/ 10W 47K ohm F R535 033-4731-15 1/16W 47K ohm R850 033-1031-15 1/16W 10K ohm
R328 032-0140-89 1/ 10W 47K ohm F R536 033-2231-15 1/16W 22K ohm R851 033-1031-15 1/16W 10K ohm
R329 032-0140-89 1/ 10W 47K ohm F R537 033-1041-15 1/16W 100K ohm R853 119-2721-15 1/10W 2.7K ohm
R332 032-0140-89 1/ 10W 47K ohm F R538 119-4711-15 1/16W 470 ohm R854 119-1021-15 1/10W 1K ohm
R333 032-0140-89 1/ 10W 47K ohm F R539 119-4711-15 1/16W 470 ohm R855 119-1021-15 1/10W 1K ohm
R334 032-0140-89 1/ 10W 47K ohm F R540 119-0000-05 1/10W 0 ohm JW R856 119-1021-15 1/10W 1K ohm
R335 032-0140-89 1/ 10W 47K ohm F R541 119-1021-15 1/10W 1K ohm R857 119-1021-15 1/10W 1K ohm
R344 119-1021-15 1/10W 1K ohm R542 119-1021-15 1/10W 1K ohm R858 033-1031-15 1/16W 10K ohm
R346 119-1041-15 1/10W 100K ohm R543 033-4721-15 1/16W 4.7K ohm R859 033-1031-15 1/16W 10K ohm
R347 119-1041-15 1/10W 100K ohm R546 119-0000-05 1/10W 0 ohm JW R860 033-1031-15 1/16W 10K ohm
R408 033-8221-15 1/16W 8.2K ohm R547 119-0000-05 1/10W 0 ohm JW R861 033-1031-15 1/16W 10K ohm
R409 033-1021-15 1/16W 1K ohm (PE-3159B-A) R862 119-6831-15 1/16W 68K ohm
R410 033-1021-15 1/16W 1K ohm R548 119-0000-05 1/10W 0 ohm JW R863 119-2231-15 1/10W 22K ohm
R411 033-4711-15 1/16W 470 ohm (PE-3159K-A/B) R865 119-3351-15 1/10W 3.3M ohm
R412 033-2231-15 1/16W 22K ohm R558 119-0000-05 1/10W 0 ohm JW R866 033-1031-15 1/16W 10K ohm
R413 033-4721-15 1/16W 4.7K ohm R560 119-0000-05 1/10W 0 ohm JW R867 119-1031-15 1/16W 10K ohm
R424 033-1231-15 1/16W 12K ohm R563 119-0000-05 1/10W 0 ohm JW R870 032-0140-54 1/ 10W 10K ohm F
R425 119-0000-05 1/10W 0 ohm JW R801 033-3311-15 1/16W 330 ohm R871 032-0140-50 1/ 10W 22K ohm F
R427 033-1021-15 1/16W 1K ohm R802 119-1031-15 1/16W 10K ohm R872 119-6221-15 1/16W 6.2K ohm
R428 033-1021-15 1/16W 1K ohm R804 033-4711-15 1/16W 470 ohm R873 119-1031-15 1/16W 10K ohm
R429 033-1021-15 1/16W 1K ohm R805 033-4721-15 1/16W 4.7K ohm R874 119-6221-15 1 /16W 6.2K ohm
R430 033-1021-15 1/16W 1K ohm R806 033-4721-15 1/16W 4.7K ohm R875 119-6821-15 1 /10W 6.8K ohm
R446 033-1031-15 1/16W 10K ohm R807 116-3391-15 1/4WS 3.3 ohm R876 033-3331-15 1/16W 33K ohm
R448 119-2231-15 1/10W 22K ohm R808 033-0000-05 0.5A 0 ohm R877 033-3331-15 1/16W 33K ohm
R449 119-2231-15 1/10W 22K ohm R809 119-0000-05 1/10W 0 ohm JW S501 013-6100-00 TACT SWITCH
R452 119-3311-15 1/10W 330 ohm R810 119-2231-15 1/10W 22K ohm SUP20 060-0122-20 DSP-141N9S00B
R453 119-3311-15 1/10W 330 ohm R811 119-1531-15 1/16W 15K ohm T101 009-9006-60 0.23mH
R454 119-2231-15 1/10W 22K ohm R812 119-2231-15 1/10W 22K ohm T101 009-9006-70 CHOKE
R455 119-3311-15 1/10W 330 ohm R813 119-2231-15 1/10W 22K ohm X501 061-1056-00 32.768KHz
R456 119-3311-15 1/10W 330 ohm R815 033-6811-15 1/16W 680 ohm X502 061-3562-90 13.5MHz
R457 119-2231-15 1/10W 22K ohm R817 033-6831-15 1/16W 68K ohm X801 060-1535-90 16.9344M
R458 033-1021-15 1/16W 1K ohm R818 033-6811-15 1/16W 680 ohm PWB 039-3206-01 PWB(WITHOUT
R459 033-1021-15 1/16W 1K ohm R820 119-1011-15 1/16W 100 ohm COMPONENT)
