Clarion CZ109 Service Manual

-7-
ELECTRICAL PARTS LIST
Main PWB(B1) section
Note)1. Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
2. Some parts depend on each model. The model name is specified in the description.
CZ109/CZ109A
REF No.
PART No. DESCRIPTION
REF No.
PART No. DESCRIPTION
REF No.
PART No. DESCRIPTION
ANT2 092-4000-51 ANT-RECEPT C507 163-1063-35 16V 10uF D502 001-4301-26 HZU4.7B2
BL1 941-0227-02 TUNER C508 043-1710-90 9pF D503 001-1323-90 L1SS355T1G
C118 043-1608-90 0.1uF C509 043-1710-90 9pF D504 001-1323-90 L1SS355T1G
C119 043-1608-90 0.1uF C510 043-1719-90 22pF D505 001-1323-90 L1SS355T1G
C120 187-1073-15 6.3V 100uF C511 043-1719-90 22pF D506 001-1323-90 L1SS355T1G
C121 043-1608-90 0.1uF C512 043-1607-90 0.01uF D507 001-1323-90 L1SS355T1G
C122 187-1073-35 16V 100uF C513 043-1601-90 100pF D508 001-1323-90 L1SS355T1G
C123 043-1608-90 0.1uF C514 042-1577-00 6.3V 100uF D509 001-4301-41 HZU7.5B2
C124 187-1073-35 16V 100uF C515 043-1607-90 0.01uF D510 001-4301-41 HZU7.5B2
C125 043-1608-90 0.1uF C516 189-1083-12 6.3V 1000uF D511 001-4301-41 HZU7.5B2
C126 043-1608-90 0.1uF C517 043-1802-90 0.01uF D512 001-4301-41 HZU7.5B2
C202 043-1727-90 47pF C518 043-1802-90 0.01uF D801 001-1323-90 L1SS355T1G
C203 043-1827-90 0.027uF C800 187-1073-15 6.3V 100uF D802 001-0644-90 MA113
C204 043-1827-90 0.027uF C801 043-1620-90 4700pF IC105 051-3349-00 HA13166
C209 187-1073-25 10V 100uF C802 043-1802-90 0.01uF IC302 051-5028-90 TDA7409
C210 187-1073-25 10V 100uF C803 043-1804-90 0.1uF IC305 051-3060-90 AZ4558
C211 043-1804-90 0.1uF C804 043-1804-90 0.1uF IC402 051-2060-00 LA47201
C212 043-1804-90 0.1uF C805 187-3363-25 6.3V 100uF IC501 052-1954-00 LC8783C8PA-59H7
C213 187-1073-25 10V 100uF C806 043-1804-90 0.1uF IC502 051-5443-38 S80850CNMC
C214 043-1804-90 0.1uF C807 187-1073-15 6.3V 100uF IC503 051-5437-58 R3111N211A
C217 043-1607-90 0.01uF C809 043-1804-90 0.1uF IC801 051-6743-00 LC786920
C218 043-1601-90 100pF C810 043-1804-90 0.1uF IC802 051-6096-90 LA6242H
C222 043-1719-90 22pF C811 043-1802-90 0.01uF J401 074-1214-50 16P
C224 187-1073-25 10V 100uF C812 043-1606-90 1000pF J501 074-1217-50 12P
C227 043-1804-90 0.1uF C813 043-1804-90 0.1uF J502 075-0393-50 JACK
C229 043-1607-90 0.01uF C814 043-1607-90 0.01uF J801 074-2246-67 17P
C230 043-1607-90 0.01uF C815 187-1073-15 6.3V 100uF L201 010-2003-04 30uH(Variable)
C231 187-3353-65 50V 3.3uF C816 168-1052-78 1uF L202 010-3105-67 1k ohm/100MHz
C242 043-1819-90 2200pF C817 043-1606-90 1000pF L203 010-3105-67 1k ohm/100MHz
C250 187-4763-35 16V 47uF C818 043-1608-90 0.1uF L206 010-6009-57 0.56uH
C307 187-1053-65 50V 1uF C819 187-1073-15 6.3V 100uF L301 010-6009-84 100uH
C308 187-1053-65 50V 1uF C820 043-1608-90 0.1uF L302 010-3105-67 1k ohm/100MHz
C309 187-1053-65 50V 1uF C821 043-1804-90 0.1uF L303 010-3105-67 1k ohm/100MHz
C310 187-1053-65 50V 1uF C822 043-1802-90 0.01uF L304 010-3105-67 1k ohm/100MHz
C311 187-1053-65 50V 1uF C824 043-1804-90 0.1uF L305 010-3105-67 1k ohm/100MHz
C312 187-1053-65 50V 1uF C825 043-1824-90 0.22uF L501 010-3112-90 1K ohm/100MHz
C313 187-4763-15 6.3V 47uF C826 043-1625-90 0.022uF L502 010-3123-90 2.2uH
C314 187-1063-35 16V 10uF C827 043-1608-90 0.1uF L503 010-3123-90 2.2uH
C315 043-1735-90 100pF C828 187-1073-15 6.3V 100uF L504 010-3123-90 2.2uH
C316 043-1735-90 100pF C829 043-1608-90 0.1uF L801 010-6009-76 22uH
C317 043-1804-90 0.1uF C830 043-1804-90 0.1uF L802 010-6009-76 22uH
C318 187-4763-35 16V 47uF C831 187-1073-15 6.3V 100uF Q123 125-9026-90 IMF29
C319 043-1735-90 100pF C833 189-3373-11 6.3V 330uF Q201 125-0025-93 RN2303-TE85L
C320 043-1735-90 100pF C834 189-4773-22 10V 470uF Q201 125-0034-93 RT1P241M
C321 187-1063-35 16V 10uF C835 043-1804-90 0.1uF Q202 125-0025-93 RN2303-TE85L
C322 187-1063-35 16V 10uF C836 163-4753-55 50V 4.7uF Q202 125-0034-93 RT1P241M
C323 187-1063-35 16V 10uF C837 163-4753-55 50V 4.7uF Q203 125-0027-92 UNR611200A
C324 187-1063-35 16V 10uF C838 043-1800-90 1000pF Q203 125-2041-93 RT1N241M
C337 187-1063-35 16V 10uF C839 043-1800-90 1000pF Q206 125-0027-92 UNR611200A
C338 187-1063-35 16V 10uF C840 043-1800-90 1000pF Q206 125-2041-93 RT1N241M
C339 187-1063-35 16V 10uF C841 043-1800-90 1000pF Q208 125-4011-90 KTD863YAT
C340 187-1063-35 16V 10uF C842 043-1731-90 68pF Q211 192-4116-51 2SC4116
C346 043-1841-90 0.047uF C843 043-1731-90 68pF Q211 192-4155-51 2SC4155
C401 042-4416-00 16V 3300uF C844 043-1608-90 0.1uF Q212 192-4116-51 2SC4116
C413 178-4742-78 0.47uF C845 043-1608-90 0.1uF Q212 192-4155-51 2SC4155
C414 178-4742-78 0.47uF C846 043-1608-90 0.1uF Q403 125-4024-90 3DG3875
C415 178-4742-78 0.47uF C847 187-1053-65 50V 1uF Q404 125-0027-95 DTC143ZUA-T106
C416 178-4742-78 0.47uF C848 187-1073-15 6.3V 100uF Q404 125-2041-96 RT1N436M
C421 043-1620-90 4700pF C849 043-1804-90 0.1uF Q405 125-2198-90 KRC110S
C428 187-1063-35 16V 10uF C850 043-1804-90 0.1uF Q409 125-0021-95 DTA143ZUA-T106
C435 178-4742-78 0.47uF C853 189-4773-22 10V 470uF Q409 125-0034-96 RT1P436M
C442 187-1053-65 50V 1uF C854 043-1841-90 0.047uF Q410 125-4012-90 KTD1304
C445 172-1041-15 0.1uF C855 043-1608-90 0.1uF Q411 125-4012-90 KTD1304
C447 043-1614-90 470pF C856 043-1804-90 0.1uF Q413 125-4012-90 KTD1304
C449 043-1614-90 470pF C857 187-1073-15 6.3V 100uF Q414 125-4012-90 KTD1304
C450 043-1614-90 470pF C858 043-1804-90 0.1uF Q500 125-4024-90 3DG3875
C451 043-1614-90 470pF C859 187-1073-15 6.3V 100uF Q501 190-1576-00 2SA1576A-T106
C452 043-1614-90 470pF C860 187-1073-15 6.3V 100uF Q501 125-3014-90 ISA1602AM1
C453 043-1614-90 470pF C861 043-1608-90 0.1uF Q502 190-1576-00 2SA1576A-T106
C454 043-1614-90 470pF C870 187-1073-35 16V 100uF Q502 125-3014-90 ISA1602AM1
C455 043-1614-90 470pF D100 001-0592-61 1N5404 Q503 125-2027-91 DTC143EUA-T106
C500 187-3363-45 10V 33uF D109 001-0466-61 1A4 Q503 125-2041-92 RT1N141M
C501 168-1052-78 1uF D110 001-0466-61 1A4 Q504 125-2027-91 DTC143EUA-T106
C502 043-1608-90 0.1uF D302 001-4316-17 LM3Z4V3T1G Q504 125-2041-93 RT1N241M
C503 043-1608-90 0.1uF D401 001-4316-24 LM3Z8V2T1G Q505 125-0034-97 RT1P237M
C504 168-1052-78 50V 1uF D402 001-1323-90 L1SS355T1G Q515 125-2027-91 DTC143EUA-T106
C505 043-1804-90 0.1uF D403 001-1323-90 L1SS355T1G Q515 125-2041-93 RT1N241M
C506 043-0540-00 16V 10uF D500 001-1323-90 L1SS355T1G Q516 125-0034-97 RT1P237M
