Clarion CZ109 Service Manual

Main section
NO. PART NO. DESCRIPTION Q'TY NO. PART NO. DESCRIPTION Q'TY
1 074-1217-50 OUTLET SOCKET
(
12P
)
122
731-2606-8B TAPTIGHT(M2.6X6)
1
2 074-2246-67 OUTLET SOCKET
(
17P
)
123
370-6394-00 INNER-ES
3
3 MAIN PWB 1 24
335-5915-01 HOOK
1
4 013-6100-00 TACT SWITCH 1 25 1
5 941-0227-02 TUNER 1 26 750-3219-00 SPRING
(
F-HOOK
)
1
6 092-4000-51 ANT-RECEPT 1 27 341-1627-00 SHAFT 1
7 075-0393-50 JACK 1 28 929-4002-00 CD MECHANISM 1
8 051-3349-00 IC 1 29 310-1871-00 UPPER CASE 1
9 051-2060-00 IC 1 30 313-2006-02 HEAT SIN
K
1
10 009-9006-60 CHOKE 1 31 731-3008-89 TAPTIGHT
(
M3X8
)
5
009-9006-70 CHOKE 1 32 714-3006-85 MACHINE SCREW
(
M3X6
)
3
11 331-4533-00 JACK HOLDER 1 33 714-2610-85 MACHINE SCREW
(
M2.6X10
)
3
12 331-3935-02 IC HOLDER 1 34 345-3799-20 RUBBER PAR
T
4
13 331-3561-03 CONNECTOR-HOLD 1 35 311-1859-05 LOWER CASE 1
14 074-1214-50 OUTLET SOCKET
(
16P
)
1 36 276-0555-00 SETPLATE
(
PE-3159B-A
)
1
15 855-5563-50 RCA PIN CORD 1 276-0559-00 SETPLATE
(
PE-3159K-A
)
1
16 854-4619-50 AUX LEAD 1 276-0560-00 SETPLATE
(
PE-3159K-B
)
1
17 347-8489-00 FILM 1 37 347-8427-00 FILM 1
18 331-4312-01 EARTH PLATE 1 38 345-6195-00 CUSHION 2
19 716-0872-61 SPECIAL SCREW 1 39 345-6201-00 CUSHION 2
20 382-8567-01 BUTTON(P) 1 40 1
21 750-6861-00 SPRING 1
Note 1)CD MECHANISM 929-4002-00 is exchanged
correspondence, it is not being possible to repair.
-6-
CZ109/CZ109A
347-8490-00 FILM
346-0194-00 LEATHER SHEET
1
2
3
4
5
16
6
7
8
9
10
11
12
13
14
15
17
18
19
20
21
22
23
23
23
24
25
26
27
28
29
30
31
32
33
31
31
34
35
36
37
38
39
39
38
40
2)Some parts depend on each model.
The model name is specified in the description
