Clarion DB135 Service Manual

- 12 -
DB135
D 201 001-7030-02 LED
J 104 816-2571-60 EXTENTION
LEAD(4PIN)
PL 201 017-0414-00 PILOT LAMP
R 201 111-3911-91 1/4WS 390 ohm
R 202 119-1521-10 1/16W 1.5K ohm
R 204 119-2221-10 1/16W 2.2K ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
R 206 119-2721-10 1/16W 2.7K ohm
R 208 119-3921-10 1/16W 3.9K ohm
R 210 119-6821-10 1/16W 6.8K ohm
R 212 119-1231-10 1/16W 12K ohm
R 214 119-3331-10 1/16W 33K ohm
S 202 013-6001-50 TACT SWITCH
S 204 013-6005-51 TACT SWITCH
S 206 013-6005-51 TACT SWITCH
S 208 013-6005-51 TACT SWITCH
S 210 013-6005-51 TACT SWITCH
S 212 013-6005-51 TACT SWITCH
S 214 013-6005-51 TACT SWITCH
S 216 013-6001-50 TACT SWITCH
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
REF No. PART No. DESCRIPTION
J 103 816-2572-60 EXTENTION
LEAD(7PIN)
PL 202 017-0414-00 PILOT LAMP
R 203 119-1521-10 1/16W 1.5K ohm
R 205 119-2221-10 1/16W 2.2K ohm
R 207 119-2721-10 1/16W 2.7K ohm
R 209 119-3921-10 1/16W 3.9K ohm
R 211 119-6821-10 1/16W 6.8K ohm
R 213 119-1231-10 1/16W 12K ohm
R 215 119-3331-10 1/16W 33K ohm
S 201 013-6005-51 TACT SWITCH
S 203 013-6005-51 TACT SWITCH
S 205 013-6005-51 TACT SWITCH
S 207 013-6005-51 TACT SWITCH
S 215 013-6005-51 TACT SWITCH
S 217 013-6005-51 TACT SWITCH
VR 1 016-9900-84 VR W/SHAFT
Right ES-PWB (B2)
Left ES-PWB (B3)
- 11 -
DB135
C 101 166-2201-00 50V 22pF
C 102 166-2201-00 50V 22pF
C 103 182-4763-12 6.3V 47uF
C 104 042-0598-90 10V 470uF
C 106 168-1032-05 50V 0.01uF
C 107 168-1045-06 25V 0.1uF
C 108 182-1073-22 10V 100uF
C 110 182-1073-22 10V 100uF
C 111 168-1032-05 50V 0.01uF
C 112 168-2732-05 50V 0.027uF
C 113 168-2732-05 50V 0.027uF
C 114 168-2232-05 50V 0.022uF
C 115 168-1022-05 50V 1000pF
C 116 178-1052-08 16V 1uF
C 117 178-1052-08 16V 1uF
C 118 178-1052-08 16V 1uF
C 119 178-1052-08 16V 1uF
C 120 182-3353-62 50V 3.3uF
C 121 168-1032-05 50V 0.01uF
C 122 182-2263-32 16V 22uF
C 123 178-1052-08 16V 1uF
C 124 178-1052-08 16V 1uF
C 125 168-1522-05 50V 1500pF
C 126 168-1522-05 50V 1500pF
C 127 168-8232-08 50V 0.082uF
C 128 168-8232-08 50V 0.082uF
C 129 168-8232-08 50V 0.082uF
C 130 168-8232-08 50V 0.082uF
C 131 178-1842-08 25V 0.18uF
C 132 178-1842-08 25V 0.18uF
C 133 178-1842-08 25V 0.18uF
C 134 178-1052-08 16V 1uF
C 135 178-1842-08 25V 0.18uF
C 136 178-1052-08 16V 1uF
C 138 182-1063-33 16V 10uF
C 139 182-1063-33 16V 10uF
C 140 182-1053-62 50V 1uF
C 142 182-1053-62 50V 1uF
C 144 178-1052-08 16V 1uF
C 145 178-1052-08 16V 1uF
C 146 178-1052-08 16V 1uF
C 147 178-1052-08 16V 1uF
C 148 166-3311-00 50V 330pF
C 149 166-1011-00 50V 100pF
C 150 172-1041-11 50V 0.1uF
C 151 166-1011-00 50V 100pF
C 152 166-1011-00 50V 100pF
C 153 172-1041-11 50V 0.1uF
C 154 182-4763-32 16V 47uF
C 155 184-4773-12 6.3V 470uF
C 156 168-1045-06 25V 0.1uF
C 157 178-2255-09 16V 2.2uF
C 160 166-2201-00 50V 22pF
C 159 172-1041-11 50V 0.1uF
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Main PWB Section (B1)
Note: Several different parts of the same reference number are alternative parts.
One of those parts is used in the set.
REF No. PART No. DESCRIPTION
C 161 166-2201-00 50V 22pF
C 162 172-1041-11 50V 0.1uF
C 163 172-1041-11 50V 0.1uF
C 164 184-2283-32 16V 2200uF
C 165 182-1053-62 50V 1uF
C 166 168-1045-06 25V 0.1uF
C 167 168-1045-06 25V 0.1uF
C 168 168-1045-06 25V 0.1uF
C 169 168-1045-06 25V 0.1uF
C 170 168-1045-06 25V 0.1uF
C 171 168-1045-06 025V .1uF
C 172 183-1056-61 50V 1uF NP
C 173 183-1056-61 50V 1uF NP
C 174 168-1032-05 50V 0.01uF
C 175 168-1045-06 25V 0.1uF
C 177 168-6822-05 50V 6800pF
C 178 168-1032-05 50V 0.01uF
C 179 182-1053-62 50V 1uF
C 180 168-1032-05 50V 0.01uF
C 181 168-4722-05 50V 4700pF
C 183 182-1073-22 10V 100uF
C 185 168-1022-05 50V 1000pF
C 186 168-1022-05 50V 1000pF
C 187 166-4711-00 50V 470pF
C 188 166-4711-00 50V 470pF
C 189 168-1022-05 50V 1000pF
C 190 168-1022-05 50V 1000pF
C 191 168-1022-05 50V 1000pF
C 192 168-1022-05 50V 1000pF
C 193 168-1045-06 25V 0.1uF
C 195 168-1022-05 50V 1000pF
C 196 182-1073-22 10V 100uF
C 197 168-1032-05 50V 0.01uF
C 199 168-1022-05 50V 1000pF
C 200 168-1045-06 25V 0.1uF
C 201 166-4711-00 50V 470pF
C 202 182-1063-32 16V 10uF
C 203 166-4711-00 50V 470pF
C 207 166-4711-00 50V 470pF
C 208 168-1022-05 50V 1000pF
C 209 182-3353-62 50V 3.3uF
C 210 168-1045-06 25V 0.1uF
C 211 178-2255-09 16V 2.2uF
C 212 184-4773-12 6.3V 470uF
C 213 182-2273-12 6.3V 220uF
C 214 166-2211-00 16V 220pF
C 215 166-2211-00 16V 220pF
C 216 166-2211-00 16V 220pF
C 217 166-2211-00 16V 220pF
C 218 166-2211-00 16V 220pF
C 219 166 2211-00 16V 220pF
C 220 166-2211-00 16V 220pF
C 221 166-2211-00 16V 220pF
C 222 168-1022-05 16V 1000pF
C 223 168-1045-06 25V 0.1uF
C 224 168-1045-06 25V 0.1uF
C 225 168-1022-05 50V 1000pF
C 226 168-1022-05 50V 1000pF
C 229 178-2242-08 25V 0.22uF
C 232 182-1073-12 6.3V 100uF
C 233 168-1045-06 25V 0.1uF
C 241 168-1032-05 50V 0.01uF
C 301 178-1052-01 16V 1uF
C 302 178-1052-01 16V 1uF
C 303 178-1052-01 16V 1uF
C 304 178-1052-01 16V 1uF
D 104 001-0466-00 S5688B
D 105 001-0466-01 S5688G
D 106 001-0466-00 S5688B
D 107 001-0592-00 RM4Z
D 108 001-0466-00 S5688B
D 109 001-0376-26 MTZJ4.7B
D 110 001-0466-00 S5688B
D 111 001-0466-00 S5688B
D 112 001-0466-00 S5688B
D 113 001-0466-00 S5688B
D 114 001-0466-00 S5688B
D 115 001-0466-00 S5688B
D 116 001-0466-00 S5688B
D 117 001-0330-00 1SS119
D 120 001-0376-35 MTZJ6.2B
D 121 001-0376-35 MTZJ6.2B
D 122 001-0330-00 1SS119
D 123 001-0466-00 S5688B
D 207 001-0330-00 1SS119
D 208 001-0330-00 1SS119
IC 101 051-5022-90 LC75421M
IC 102 051-2031-31 LA4763
IC 103 052-1932-00 TC9324F-006
IC 104 051-3295-00 HA13164A
L 101 010-2003-04 COIL
L 102 010-2330-67 5.6uH
L 103 010-2330-86 220uH
L 104 010-2330-50 0.22uH
Q 101 100-1048-00 2SA1048
Q 102 125-2004-02 RN1402
Q 103 100-1298-00 2SA1298 O,Y
Q 104 125-2004-02 RN1402
Q 105 102-2712-51 2SC2712GR
Q 106 125-2004-03 RN1403
Q 107 102-2712-51 2SC2712GR
Q 108 125-0002-03 RN2403
Q 109 103-1306-00 D1306
Q 110 103-1306-00 D1306
Q 112 125-0002-04 RN2404
Q 113 102-2712-51 2SC2712GR
Q 114 100-1298-00 2SA1298 O,Y
Q 117 125-2004-02 RN1402
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTIONREF No. PART No. DESCRIPTION
Q 118 102-2712-51 2SC2712GR
Q 119 102-2712-51 2SC2712GR
Q 120 100-1298-00 2SA1298 O,Y
Q 121 125-2004-03 RN1403
Q 122 102-2712-51 2SC2712GR
Q 123 102-2712-51 2SC2712GR
R 101 119-2221-10 1/16W 2.2K ohm
R 102 111-2221-91 1/4WS 2.2K ohm
R 103 119-2231-10 1/16W 22K ohm
R 104 111-1021-91 1/4WS 1K ohm
R 105 119-1011-10 1/16W 100 ohm
R 106 111-2221-91 1/4WS 2.2K ohm
R 107 119-2221-10 1/16W 2.2K ohm
R 108 119-2231-10 1/16W 22K ohm
R 109 119-1021-10 1/16W 1K ohm
R 110 119-1031-10 1/16W 10K ohm
R 112 119-3331-10 1/16W 33K ohm
R 113 119-3331-10 1/16W 33K ohm
R 115 119-1231-10 1/16W 12K ohm
R 116 111-4721-91 1/4WS 4.7K ohm
R 117 119-1021-10 1/16W 1K ohm
R 118 119-1021-10 1/16W 1K ohm
R 119 119-4741-10 1/16W 470K ohm
R 120 119-8221-10 1/16W 8.2K ohm
R 121 119-8221-10 1/16W 8.2K ohm
R 122 119-3921-10 1/16W 3.9K ohm
R 123 119-3921-10 1/16W 3.9K ohm
R 124 119-1031-10 1/16W 10K ohm
R 125 119-1031-10 1/16W 10K ohm
R 126 119-1031-10 1/16W 10K ohm
R 127 119-1031-10 1/16W 10K ohm
R 128 119-1031-10 1/16W 10K ohm
R 129 119-1031-10 1/16W 10K ohm
R 130 119-1031-10 1/16W 10K ohm
R 131 119-1031-10 1/16W 10K ohm
R 132 119-2221-10 1/16W 2.2K ohm
R 133 119-2221-10 1/16W 2.2K ohm
R 134 119-2221-10 1/16W 2.2K ohm
R 135 119-2221-10 1/16W 2.2K ohm
R 136 119-1031-10 1/16W 10K ohm
R 137 119-1031-10 1/16W 10K ohm
R 138 119-1041-10 1/16W 100K ohm
R 139 119-3311-10 1/16W 330 ohm
R 140 119-3311-10 1/16W 330 ohm
R 141 119-2221-10 1/16W 2.2K ohm
R 142 119-1041-10 1/16W 100K ohm
R 143 119-1041-10 1/16W 100Kohm
R 144 119-4731-10 1/16W 47K ohm
R 145 119-4731-10 1/16W 47K ohm
R 146 119-4731-10 1/16W 47K ohm
R 147 119-5631-10 1/16W 56K ohm
R 150 119-1231-10 1/16W 12K ohm
R 151 111-2231-91 1/4WS 22K ohm
R 154 119-8221-10 1/16W 8.2K ohm
R 155 119-2231-10 1/16W 22K ohm
R 156 119-4731-10 1/16W 47K ohm
R 158 119-1031-10 1/16W 10K ohm
R 159 119-1031-10 1/16W 10K ohm
R 163 060-0108-90 1/4WS 0 ohm
R 165 119-4731-10 1/16W 47K ohm
R 167 119-2231-10 1/16W 22K ohm
R 168 119-1031-10 1/16W 10K ohm
R 169 119-4731-10 1/16W 47K ohm
R 170 119-1831-10 1/16W 18K ohm
R 171 119-1031-10 1/16W 10K ohm
R 172 111-1021-91 1/4WS 1K ohm
R 173 119-4721-10 1/16W 4.7K ohm
R 175 119-1231-10 1/16W 12K ohm
R 176 119-1031-10 1/16W 10K ohm
R 179 119-4731-10 1/16W 47K ohm
R 180 119-3931-10 1/16W 39K ohm
R 181 119-1041-10 1/16W 100K ohm
R 182 119-1021-10 1/16W 1K ohm
R 183 119-1021-10 1/16W 1K ohm
R 184 119-1031-10 1/16W 10K ohm
R 186 119-4731-10 1/16W 47Kohm
RCA101 855-8000-08 RCA PIN CORD
SUP101 060-0122-20 DSP-141N-S00B
T 101 009-9006-60 CHOKE
X 101 061-1064-00 4.5MHz
