Clarion DB265MP

Switch PWB (B2) section
CD mechanism section: 929-5003-80
SENSOR PWB (B3) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R26 119-2221-15 1/10W 2.2k ohm R613 119-1021-15 1/10W 1k ohm R803 032-0162-50 1/10W 0.51ohm
R31 119-5631-15 1/10W 56k ohm R614 119-2241-15 1/10W 220k ohm R804 119-6821-15 1/10W 6.8k ohm
R35 119-1021-15 1/10W 1k ohm R615 119-1021-15 1/10W 1k ohm R805 119-4731-15 1/10W 47k ohm
R37 119-1031-15 1/10W 10k ohm R616 119-1021-15 1/10W 1k ohm R806 119-2731-15 1/10W 27k ohm
R38 119-1041-15 1/10W 100k ohm R617 119-2221-15 1/10W 2.2k ohm R807 119-2731-15 1/10W 27k ohm
R39 119-6821-15 1/10W 6.8k ohm R618 119-3321-15 1/10W 3.3k ohm R808 119-2231-15 1/10W 22k ohm
R100 119-1031-15 1/10W 10k ohm R620 119-1011-15 1/10W 100 ohm R809 119-4731-15 1/10W 47k ohm
R101 119-1021-15 1/10W 1k ohm R621 119-1021-15 1/10W 1k ohm R810 119-3341-15 1/10W 330k ohm
R102 116-2231-15 1/4W 22k ohm R622 119-1011-15 1/10W 100 ohm R811 119-4731-15 1/10W 47k ohm
R103 119-1021-15 1/10W 1k ohm R623 119-0000-05 1/10W 0 ohm JW R812 119-1531-15 1/10W 15k ohm
R104 119-1021-15 1/10W 1k ohm R624 119-1021-15 1/10W 1k ohm R813 119-8231-15 1/10W 82k ohm
R105 119-0000-05 1/10W 0 ohm JW R625 119-1021-15 1/10W 1k ohm R814 119-5621-15 1/10W 5.6k ohm
R106 119-1021-15 1/10W 1k ohm R626 119-1021-15 1/10W 1k ohm R815 119-2731-15 1/10W 27k ohm
R107 119-1031-15 1/10W 10k ohm R627 119-1021-15 1/10W 1k ohm R816 119-8231-15 1/10W 82k ohm
R108 119-1231-15 1/10W 12k ohm R628 119-1031-15 1/10W 10k ohm R817 119-2731-15 1/10W 27k ohm
R500 119-5611-15 1/10W 560 ohm R629 119-1021-15 1/10W 1k ohm R818 119-1831-15 1/10W 18k ohm
R501 119-3311-15 1/10W 330 ohm R630 119-1021-15 1/10W 1k ohm R819 119-1031-15 1/10W 10k ohm
R502 119-5621-15 1/10W 5.6k ohm R631 119-1021-15 1/10W 1k ohm R820 119-1001-15 1/10W 10 ohm
R503 119-3901-15 1/10W 39 ohm R632 119-1021-15 1/10W 1k ohm R822 119-2211-15 1/10W 220 ohm
R504 119-1031-15 1/10W 10kohm R633 119-1031-15 1/10W 10k ohm R823 119-6811-15 1/10W 680 ohm
R505 119-3901-15 1/10W 39 ohm R634 119-1031-15 1/10W 10k ohm R824 119-1051-15 1/10W 1M ohm
R506 119-3901-15 1/10W 39 ohm (PE-2793B-A) R825 119-6811-15 1/10W 680 ohm
R507 119-5621-15 1/10W 5.6k ohm R635 119-1031-15 1/10W 10k ohm R826 119-2221-15 1/10W 2.2k ohm
R508 119-1031-15 1/10W 10k ohm (PE-2793K-A/B) R827 119-1041-15 1/10W 100k ohm
R509 119-3901-15 1/10W 39 ohm R636 119-1031-15 1/10W 10k ohm R828 119-4731-15 1/10W 47k ohm
R510 119-5611-15 1/10W 560 ohm R637 119-1031-15 1/10W 10k ohm R829 119-2231-15 1/10W 22k ohm
R511 119-3311-15 1/10W 330 ohm R638 119-1031-15 1/10W 10k ohm R830 119-2221-15 1/10W 2.2k ohm
R512 119-5621-15 1/10W 5.6k ohm R639 119-1041-15 1/10W 100k ohm R831 119-2221-15 1/10W 2.2k ohm
R513 119-5621-15 1/10W 5.6k ohm R640 119-1041-15 1/10W 100k ohm R832 119-4721-15 1/10W 4.7k ohm
R514 119-4721-15 1/10W 4.7k ohm R641 119-4731-15 1/10W 47k ohm R833 119-4721-15 1/10W 4.7k ohm
R515 119-1031-15 1/10W 10k ohm R642 119-4731-15 1/10W 47k ohm R834 119-4721-15 1/10W 4.7k ohm
R516 119-1031-15 1/10W 10k ohm R644 119-1031-15 1/10W 10k ohm R835 119-2211-15 1/10W 220 ohm
R517 119-1831-15 1/10W 18k ohm R645 119-1001-15 1/10W 10 ohm R836 119-2211-15 1/10W 220 ohm
R518 119-1831-15 1/10W 18k ohm R646 116-1021-15 1/4W 1k ohm R837 119-3321-15 1/10W 3.3k ohm
R600 119-1541-15 1/10W 150k ohm R647 119-1041-15 1/10W 100k ohm R838 119-2221-15 1/10W 2.2k ohm
R601 119-1031-15 1/10W 10k ohm R648 119-5631-15 1/10W 56k ohm R839 119-3321-15 1/10W 3.3k ohm
R602 119-0000-05 1/10W 0 ohm JW R649 116-2231-15 1/4W 22k ohm S600 013-6103-00 TACT SWITCH
R603 119-1031-15 1/10W 10k ohm R650 119-5631-15 1/10W 56k ohm SUP1 060-0122-20 DSP-141N-S00B
R604 119-4731-15 1/10W 47k ohm R651 119-6831-15 1/10W 68k ohm X2 061-1066-00 7.2MHz
R605 119-1031-15 1/10W 10k ohm R652 119-4731-15 1/10W 47k ohm X3 060-1535-90 16.934MHz
R607 119-1021-15 1/10W 1k ohm R653 116-1221-15 1/4W 1.2k ohm X4 060-1535-90 16.934MHz
R609 119-1021-15 1/10W 1k ohm R654 119-1031-15 1/10W 10k ohm X5 061-1081-50 12.00MHz
R610 119-1021-15 1/10W 1k ohm R800 119-2211-15 1/10W 220 ohm PWB 039-2820-00 PWB(WITHOUT
R611 119-0000-05 1/10W 0 ohm JW R801 119-1001-15 1/10W 10 ohm COMPONENT)
R612 119-1021-15 1/10W 1k ohm R802 119-2231-15 1/10W 22k ohm
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C701 168-4732-78 25V 0.047uF D710 001-4301-29 HZU5.1B2
R702 119-4731-15 1/10W 47k ohm
C702 168-4732-78 25V 0.047uF D712 001-1310-00 KDS160
R703 119-6841-15 1/10W 680k ohm
C703 168-4732-78 25V 0.047uF IC702 051-6013-00 LC75854
R704 119-2231-15 1/10W 22k ohm
C704 168-1022-55 50V 1000pF IC702
051-6013-50 PT6554LQ
R712 119-4711-15 1/10W 470 ohm
C706 042-0423-97 16V 10uF IR701 060-4017-90 RS-171-T
R714 119-6811-15 1/10W 680 ohm
C707 042-0423-97 16V 10uF
J702 076-0615-50
12P
R715 119-8211-15 1/10W 820 ohm
CCT701 050-0149-52
1/32W 2.2k ohm (x4)
LCD702 379-1352-41
INDICATOR(LCD)
R717 119-1021-15 1/10W 1k ohm
D701 001-7046-01 DIODE
PL701 017-0444-00
PILOLAMP
R718 119-1011-15 1/10W 100 ohm
D702 001-4907-90
PG05GBUSU
(14V 50mA)
S719 016-9900-84 VR W/SHAFT
D707 001-4301-41 HZU7.5B2
PL702 017-0444-00 PILOLAMP
PWB 039-2821-00 PWB(WITHOUT
D709 001-4301-38 HZU6.8B2
(14V 50mA)
COMPONENT)
REF No.
PART No.
DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
D1 001-7058-90 AN1105W-RR Q1 060-4015-91 PS1192HB S2 013-7413-50 SPVG12
D2 001-7058-90 AN1105W-RR Q2 060-4015-91 PS1192HB PWB 039-2675-20 PWB(WITHOUT
J1 074-1138-60 10P S1 013-7414-50 SPVG22 COMPONENT)
-11-
DB265MP/DB266MP
