Clarion NX302E Installation Guide

English
16
NX302E
Installation Guide
C
18
16
14
12
10
8
6
4
2
17
15
13
11
9
7
5
3
1
A
1
3
5
7
2
4
6
8
B
1
3
5
7
2
4
6
8
d
VW, Audi
Rear right (+) / Purple
Rear right (-) / Purple with black stripe
Front right (+) / Gray
Battery 12V(+) / Yellow
Front right (-) / Gray with black stripe
Auto Antenna / Blue
Front left (+) / White
Illumination / Orange with white stripe Front left (-) / White with black stripe
ACC+ / Red Rear left (+) / Green
Ground / Black Rear left (-) / Green with black stripe
YellowYellow
Red Red
Function
Connector A Connector B
Location
Rear right -
Front right -
Front left +
Rear left +
AUTO ANT
ACC +
Parking
Reverse
Ground
Rear right +
Front right +
Front left -
Rear left -
Illumination
AMP Remote
Phone Mute
Battery +
Fuse 15A

Clarion NX302E Specifications

General

MP3 playback	Yes
CD-R playback	-
Audio formats supported	MP3, WMA
Video formats supported	MPEG4
AM band range	531 - 1602 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Aspect ratio	16:9
Display type	TFT
Display diagonal	6.2 \
Display resolution	800 x 480 pixels
Number of OSD languages	10
On Screen Display (OSD) languages	CZE, DEU, DUT, ENG, ESP, FRE, GRE, ITA, POL, SWE
DIN size	2 DIN
Output power	21 W
Product color	Black
Analog signal format system	NTSC, PAL
Bluetooth profiles	A2DP, AVRCP, DUN, HFP, HSP, OPP, PBAP
Bluetooth functions	Audiostreaming, Handsfree calling
Menu languages	ARA, BUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, NOR, POL, POR, RUS, SER, SLV, SWE, TUR, UKR
Power requirements	10.8 - 15.6
Compatible memory cards	MicroSD (TransFlash)

Weight and Dimensions

Weight	1450 g
Dimensions (WxDxH)	178 x 163 x 100 mm
