Clarion PN-2940S-C User Manual

929-0383-80
- M2 -
pin 73: T CLR : O : The clear signal output for the test mode
indication.
pin 74: NU : - : Not in use.
pin 75: NU : - : Not in use.
pin 76: NU : - : Not in use.
pin 77: NU : - : Not in use.
pin 78: FL BOOT :IN: Flash memory control.
pin 79: TEST 1 :IN: For the test.
pin 80: TEST 2 :IN: For the test.
pin 81: TEST 3 :IN: For the test.
pin 82: TEST 4 :IN: For the test.
pin 83: I2C REQ : O : Transmit request signal output.
pin 84: I2C SDA :I/O: I2C serial data input/output.
pin 85: I2C SCL :I/O:I2C serial clock input/output.
pin 86: ACC DET :IN: ACC detection signal input.
pin 87: NU : - : Not in use.
pin 88: SW 1 :IN: The switch signal input.
pin 89: VCC : - : Positive voltage supply.
pin 90: SW 2 :IN: The switch signal input.
pin 91: VSS : - : Negative voltage supply.
pin 92: SW 3 :IN: The switch signal input.
pin 93: SW 4 :IN: The switch signal input.
pin 94: NU : - : Not in use.
pin 95: PT 1 :IN: The photo sensor signal input.
pin 96: PT 2 :IN: The photo sensor signal input.
pin 97: PT 3 :IN: The photo sensor signal input.
pin 98: PT 4 :IN: The photo sensor signal input.
pin 99: PT 5 :IN: The photo sensor signal input.
pin100: Vref H : - : Reference voltage.

Clarion PN-2940S-C Specifications

General

Brand	Clarion
Model	PN-2940S-C
Category	Car Video System
Language	English
