PS-3025K-A,B
SOLDER SIDE
Caution:
SOLDER SIDE: Parts on the solder side seen
from the solder side are indicated.
Main PWB(B1) section 2/2
ANT101
J801
IC391
24
25 1
2
J701
J721
113
2
3
7
11
12
10
645
8
9
1
5
234
8
BL101
26
1
CATS TP
13P (Ce-NET)
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
No
1
GROUND
2
BACK UP
3
L-CH INPUT(+)
4
N.C.
N.C.
5
6
BUS (+)
7
R-CH INPUT(+)
R-CH INPUT(-)
8
9
SYS-ACC
10
BUS (-)
11
L-CH INPUT(-)
12
13
ILLUMINATION (+)
N.C.
Description
J701
Ce-NET
1213
3456
7
8 910
11 12
No
1
GROUND
2
ACC
3
AUX L-CH (+)
4
N.C.
N.C.
5
6
AUX-ON
7
AUX R-CH (+)
8
Description
J721
S-GROUND
No
Description
A-ANT
REAR SP R-CH (+)
REAR SP L-CH (+)
FRONT SP R-CH (+)
ILLUMINATION (+)
SPEED PULSE
BACK UP
SR-G
ACC
FRONT SP L-CH (+)
REAR SP R-CH (-)
REAR SP L-CH (-)
FRONT SP R-CH (-)
FRONT SP L-CH (-)
ILLUMINATION (-)
GROUND
No
Description
SR-1
N.C
N.C
N.C
J801
IC272
IC741
1
4
4
1
TM801
X121
ABCDEF
G
H
IJ
KLMNOP
Q
RS T
8
7
6
5
1
3
2
4
R
H
A
B
C
D
E
F
G
I
J
K
L
M
N
O
P
Q
S
T
