Clarion PS-3025K-A User Manual

PS-3025K-A,B
- 8 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
Main PWB section (B1)
ANT101 092-0702-00 ANT-RECEPT
BL101 941-0215-80 TUNER PACK
(PS-3025K-A)
941-0221-80 TUNER PACK
(PS-3025K-B)
C101 168-1022-55 1000pF K
C103 168-1022-55 1000pF K
C104 188-1073-28 10V 100uF
C105 168-1042-78 16V 0.1uF
C106 168-1042-78 16V 0.1uF
C107 188-1073-28 10V 100uF
C108 168-1042-78 16V 0.1uF
C109 168-2232-55 0.022uF K
C112 168-4745-79 0.47uF Z
C113 168-6832-78 0.068uF K
C114 168-6832-78 0.068uF K
C121 166-1501-50 15pF CH
C123 168-1042-78 16V 0.1uF
C124 042-1458-90 50V 1uF LN
C125 166-1501-50 15pF CH
C126 166-1011-50 100pF CH
C127 166-1011-50 100pF CH
C128 166-1011-50 100pF CH
C129 166-1011-50 100pF CH
C130 168-2232-55 0.022uF K
C131 188-4763-38 16V 47uF
C134 166-1011-50 100pF CH
C151 188-3363-27 10V 33uF
C152 178-1052-78 1uF
C153 188-4753-57 35V 4.7uF
C154 168-1042-78 16V 0.1uF
C155 168-2232-55 0.022uF K
C156 166-6811-50 680pF
C157 168-2232-55 0.022uF K
C158 166-8211-50 820pF
C159 168-1032-55 0.01uF K
C161 188-4763-18 6.3V 47uF
C162 168-1042-78 16V 0.1uF
C163 166-5611-50 560pF CH
C164 168-1032-55 0.01uF K
C165 166-3901-50 39pF CH
C166 166-3311-50 330pF CH
C167 188-2253-68 50V 2.2uF
C168 166-3901-50 39pF CH
C169 168-1822-55 1800pF K
C170 168-8222-55 8200pF K
C171 168-2232-55 0.022uF K
C212 188-4763-38 16V 47uF
C222 168-1042-78 16V 0.1uF
C241 168-2232-55 0.022uF K
C243 188-4763-38 16V 47uF
C244 168-1042-78 16V 0.1uF
C245 168-1042-78 16V 0.1uF
C274 189-2273-29 10V 220uF
C276 043-0328-90 0.1uF
C301 178-1052-78 1uF
C302 178-1052-78 1uF
C305 178-1052-78 1uF
C306 178-1052-78 1uF
C309 168-1832-55 0.018uF K
C310 168-1832-55 0.018uF K
C311 188-2253-68 50V 2.2uF
C312 188-2253-68 50V 2.2uF
C313 188-2253-68 50V 2.2uF
C314 188-2253-68 50V 2.2uF
C318 168-1522-55 1500pF K
C319 168-1522-55 1500pF K
C334 166-4711-50 470pF CH
C335 166-4711-50 470pF CH
C346 188-1073-28 10V 100uF
C352 168-1042-78 16V 0.1uF
C353 042-1562-15 10V 220uF
C354 166-2201-50 22pF CH
C355 166-2201-50 22pF CH
C356 166-1007-50 10pF CH
C357 166-1007-50 10pF CH
C358 188-1063-38 16V 10uF
C359 188-1063-38 16V 10uF
C360 188-1063-38 16V 10uF
C361 188-1063-38 16V 10uF
C391 168-1042-78 16V 0.1uF
C392 168-1042-78 16V 0.1uF
C393 168-1042-78 16V 0.1uF
C394 168-1042-78 16V 0.1uF
C395 168-1032-55 0.01uF K
C396 163-1053-65 50V 1uF
C397 042-1624-00 4700 16V
C398 163-1063-35 16V 10uF
C399 163-1053-65 50V 1uF
C400 166-2201-50 22pF CH
C401 166-3911-50 390pF CH
C402 043-0570-90 16V 2.2uF K
C403 168-5632-78 16V 0.056uF
C404 043-0570-90 16V 2.2uF K
C405 188-1063-38 16V 10uF
C406 188-1073-28 10V 100uF
C407 168-1042-78 16V 0.1uF
C408 166-3911-50 390pF CH
C409 043-0570-90 16V 2.2uF K
C410 168-5632-78 16V 0.056uF
C411 043-0570-90 16V 2.2uF K
C412 168-1042-78 16V 0.1uF
C417 178-4742-78 0.47uF
C418 168-4722-55 4700pF K
C419 178-4742-78 0.47uF
C420 168-4722-55 4700pF K
C421 178-4742-78 0.47uF
C422 168-4722-55 4700pF K
C423 178-4742-78 0.47uF
C424 168-4722-55 4700pF K
C501 168-1042-78 16V 0.1uF
C502 188-4763-18 6.3V 47uF
C503 168-1032-55 0.01uF K
C504 168-1032-55 0.01uF K
C505 168-1032-55 0.01uF K
C506 168-1042-78 16V 0.1uF
C507 188-1053-68 50V 1uF
C509 168-1022-55 1000pF K
C510 168-1022-55 1000pF K
C511 168-1042-78 16V 0.1uF
C512 168-1032-55 0.01uF K
C513 189-1073-29 10V 100uF
C514 168-1042-78 16V 0.1uF
C515 166-1011-50 100pF CH
C516 188-1063-38 16V 10uF
C517 042-0559-00 0.1F 5.5V
C722 168-1042-78 16V 0.1uF
C731 172-1041-15 0.1uF
C732 188-1053-68 50V 1uF
C741 043-0328-90 0.1uF
C744 188-1073-28 10V 100uF
C761 188-1063-38 16V 10uF
C762 188-1063-38 16V 10uF
C771 188-1073-28 10V 100uF
C772 188-1063-38 16V 10uF
C773 168-1042-78 16V 0.1uF
C774 178-4755-79 4.7uF
C811 172-1041-15 0.1uF
C821 188-1063-38 16V 10uF
CCT501 050-0140-54 1/32W 1k ohm x4J
CCT504 050-0140-54 1/32W 1k ohm x4J
CCT505 050-0140-54 1/32W 1k ohm x4J
D151 001-0580-90 1SS352
D152 001-0580-90 1SS352
D391 001-0580-90 1SS352
D504 001-0580-90 1SS352
D505
001-0580-90 1SS352
D506 001-2403-90 M1F60
D507 001-4301-25 HZU4.7B1
D508 001-0466-90 S5688B
D509 001-0504-36 HZS7A1L
D701 001-0424-31 MA4180
D702 001-0424-31 MA4180
D703 001-0424-31 MA4180
D711 001-0466-90 S5688B
D712 001-0466-90 S5688B
D731 001-0466-90 S5688B
D761 001-0504-39 HZS7B2L
D771 001-0347-43 MA4082LTA
D772 001-0347-24 MA4043H
D801 001-0592-00 RM4Z
D851 001-4301-68 HZU18B1
IC121 051-6201-90 LC72146M
IC151 051-3034-90 NJM4558V
IC152 051-4607-90 SAA6581T
IC241 051-3367-90 NJU7780U1-33-TE2
IC272 051-3334-00 NJM2396F0
IC351 051-3034-90 NJM4558V
IC391 051-2040-00 TA8276H
IC401 051-5046-90 CL7639V20
IC501 052-3211-01 M30624MGP-D92GP
IC502 051-0869-58 NJM2103M
IC503 051-9400-29 BR93L46F-W
IC504 051-6600-58 HA12187FP
IC741 051-3369-00 NJM2388F8
J241 074-1237-69 19PIN
J701 074-1194-00 13PIN
J721 074-1302-08 8PIN
J801 074-4007-20 20PIN
L101 010-2003-04 30uH
L102 010-6009-76 22uH J
L103 010-6009-76 22uH J
L121 010-6009-76 22uH J
L151 010-6027-00 220uH J
L501 010-6009-76 22uH J
L502 010-6009-76 22uH J
L801 010-8026-00 210uH
P501 076-3011-74 24P PLUG
Q121 191-1197-50 2SB1197K Q,R
Q122 191-1197-50 2SB1197K Q,R
Q123 191-1197-50 2SB1197K Q,R
Q151 125-2041-92 RT1N141M
Q152 192-4155-51 2SC4155A S,T
Q153 125-0034-92 RT1P141M
Q154 125-2041-92 RT1N141M
Q155 198-0669-00 2SK669
Q156 125-0034-92 RT1P141M
Q157 125-2041-92 RT1N141M
Q158 125-2041-92 RT1N141M
Q159 125-2038-92 RN1902
Q241 125-0034-92 RT1P141M
Q242 125-2041-92 RT1N141M
Q243 193-0601-00 2SD601A
Q244 192-4155-51 2SC4155A S,T
Q245 125-2041-92 RT1N141M
Q246 125-0034-92 RT1P141M
Q247 125-2041-92 RT1N141M
Q248 198-3018-00 2SK3018
Q249 198-3018-00 2SK3018
Q391 125-2041-92 RT1N141M
Q392 192-4155-51 2SC4155A S,T
Q502 190-2071-00 2SA2071 T100
Q503 192-4155-51 2SC4155A S,T
Note)Some parts depend on each model.The model name is specified in the description.
