PS-3025K-A,B
- 9 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
R258 119-4731-15 1/10W 47k ohm
R271 119-4731-15 1/10W 47k ohm
R273 119-0000-05 1/10W 0 ohm JW
R301 119-1021-15 1/10W 1k ohm
R302 119-1021-15 1/10W 1k ohm
R305 119-1021-15 1/10W 1k ohm
R306 119-1021-15 1/10W 1k ohm
R309 119-1021-15 1/10W 1k ohm
R310 119-1021-15 1/10W 1k ohm
R311 119-5631-15 1/10W 56k ohm
R312 119-5631-15 1/10W 56k ohm
R313 119-5631-15 1/10W 56k ohm
R314 119-5631-15 1/10W 56k ohm
R323 119-0000-05 1/10W 0 ohm JW
R324 119-0000-05 1/10W 0 ohm JW
R325 119-0000-05 1/10W 0 ohm JW
R326 119-0000-05 1/10W 0 ohm JW
R351 119-8211-15 1/10W 820 ohm
R352 119-1021-15 1/10W 1k ohm
R353 032-0140-50 1/10W 10k ohm F
R354 032-0140-50 1/10W 10k ohm F
R355 032-0140-50 1/10W 10k ohm F
R356 032-0140-50 1/10W 10k ohm F
R357 032-0140-50 1/10W 10k ohm F
R358 032-0140-50 1/10W 10k ohm F
R359 032-0140-50 1/10W 10k ohm F
R360 032-0140-50 1/10W 10k ohm F
R391 119-5631-15 1/10W 56k ohm
R392 119-1221-15 1/10W 1.2k ohm
R393 119-2221-15 1/10W 2.2k ohm
R394 119-2221-15 1/10W 2.2k ohm
R395 119-2221-15 1/10W 2.2k ohm
R396 119-2221-15 1/10W 2.2k ohm
R397 119-1031-15 1/10W 10k ohm
R398 119-4731-15 1/10W 47k ohm
R399 119-4731-15 1/10W 47k ohm
R400 119-1031-15 1/10W 10k ohm
R401 119-2231-15 1/10W 22k ohm
R402 119-2021-15 1/10W 2k ohm
R403 119-2231-15 1/10W 22k ohm
R404 119-2021-15 1/10W 2k ohm
R405 119-0000-05 1/10W 0 ohm JW
R502 119-4721-15 1/10W 4.7k ohm
R503 119-4721-15 1/10W 4.7k ohm
R504 119-4721-15 1/10W 4.7k ohm
R510 119-4721-15 1/10W 4.7k ohm
R511 119-4721-15 1/10W 4.7k ohm
R512 119-4721-15 1/10W 4.7k ohm
R513 119-4721-15 1/10W 4.7k ohm
R514 119-1021-15 1/10W 1k ohm
R515 119-1041-15 1/10W 100k ohm
R516 119-1041-15 1/10W 100k ohm
R517 116-1001-15 1/4W 10 ohm
R520 119-4731-15 1/10W 47k ohm
R521 119-4731-15 1/10W 47k ohm
R522 119-4731-15 1/10W 47k ohm
R524 119-1521-15 1/10W 1.5k ohm
R525 119-1021-15 1/10W 1k ohm
R526 119-3311-15 1/10W 330 ohm
R527 119-4721-15 1/10W 4.7k ohm
R528 032-0140-66 1/10W 220 ohm F
R529 119-1031-15 1/10W 10k ohm
R530 119-1041-15 1/10W 100k ohm
R531 119-1031-15 1/10W 10k ohm
R532 119-4721-15 1/10W 4.7k ohm
R533 119-4721-15 1/10W 4.7k ohm
R534 119-1021-15 1/10W 1k ohm
R535 119-1031-15 1/10W 10k ohm
R536 119-2221-15 1/10W 2.2k ohm
R537 119-1031-15 1/10W 10k ohm
R538 119-1031-15 1/10W 10k ohm
R539 119-1031-15 1/10W 10k ohm
R540 119-4731-15 1/10W 47k ohm
R541 119-5621-15 1/10W 5.6k ohm
R542 119-2231-15 1/10W 22k ohm
R544 119-4731-15 1/10W 47k ohm
R545 119-6831-15 1/10W 68k ohm
R546 119-1021-15 1/10W 1k ohm
R547 119-1021-15 1/10W 1k ohm
R548 119-1031-15 1/10W 10k ohm
R549 119-3341-15 1/10W 330k ohm
R550 032-0140-22 1/10W 68k ohm F
R551 032-0140-00 1/10W 56k ohm F
R552 117-6821-15 1/8W 6.8k ohm
R553 119-4731-15 1/10W 47k ohm
R554 119-4731-15 1/10W 47k ohm
R555 119-5621-15 1/10W 5.6k ohm
R556 119-1021-15 1/10W 1k ohm
R557 119-4731-15 1/10W 47k ohm
R558 119-1031-15 1/10W 10k ohm
R559 119-1021-15 1/10W 1k ohm
R560 119-1021-15 1/10W 1k ohm
R561 119-1021-15 1/10W 1k ohm
R562 119-1021-15 1/10W 1k ohm
R563 119-0000-05 1/10W 0 ohm JW
R564 119-1021-15 1/10W 1k ohm
R566 119-1021-15 1/10W 1k ohm
R568 119-4731-15 1/10W 47k ohm
R569 119-4731-15 1/10W 47k ohm
R572 119-4731-15 1/10W 47k ohm
R573 119-4731-15 1/10W 47k ohm
R576 119-0000-05 1/10W 0 ohm JW
R701 116-1211-15 1/4W 120 ohm
R702 116-6801-15 1/4W 68 ohm
R703 119-2231-15 1/10W 22k ohm
R704 119-2231-15 1/10W 22k ohm
R711 116-2221-15 1/4W 2.2k ohm
R712 117-1031-15 1/8W 10k ohm
R713 116-2221-15 1/4W 2.2k ohm
R714 119-1031-15 1/10W 10k ohm
R715 119-3321-15 1/10W 3.3k ohm
R726 119-1021-15 1/10W 1k ohm
R731 116-5621-15 1/4W 5.6k ohm
R732 116-4721-15 1/4W 4.7k ohm
R761 032-0092-56 1/8W 22k ohm F
R762 119-1541-15 1/10W 150k ohm
R763 032-0092-51 1/8W 1k ohm F
R764 119-1221-15 1/10W 1.2k ohm
R771 119-0000-05 1/10W 0 ohm JW
R772 119-2231-15 1/10W 22k ohm
R773 116-1021-15 1/4W 1k ohm
R775 119-2231-15 1/10W 22k ohm
R776 119-2231-15 1/10W 22k ohm
R777 117-4731-15 1/8W 47k ohm
R778 119-1031-15 1/10W 10k ohm
R779 116-1821-15 1/4W 1.8k ohm
R780 117-1821-15 1/8W 1.8k ohm
R783 119-2231-15 1/10W 22k ohm
R793 119-0000-05 1/10W 0 ohm JW
R801 119-0000-05 1/10W 0 ohm JW
R802 119-0000-05 1/10W 0 ohm JW
R821 116-1031-15 1/4W 10k ohm
R822 119-3321-15 1/10W 3.3k ohm
R823 119-1031-15 1/10W 10k ohm
R824 116-2221-15 1/4W 2.2k ohm
R825 116-2221-15 1/4W 2.2k ohm
R826 119-8221-15 1/10W 8.2k ohm
R903 119-0000-05 1/10W 0 ohm JW
(PS-3025K-B)
R904 119-0000-05 1/10W 0 ohm JW
(PS-3025K-B)
R905 119-0000-05 1/10W 0 ohm JW
(PS-3025K-B)
R908 119-0000-05 1/10W 0 ohm JW
(PS-3025K-A)
SUP101
060-0122-20 DSP-141N-S00B
Q504 192-4155-51 2SC4155A S,T
Q505 192-4155-51 2SC4155A S,T
Q506 193-2118-50 2SD2118F5 R,S
Q701 192-4155-51 2SC4155A S,T
Q711 190-2071-00 2SA2071 T100
Q712 192-4155-51 2SC4155A S,T
Q761 192-5810-00 2SC5810 TE12L
Q762 125-0034-92 RT1P141M
Q763 125-2041-92 RT1N141M
Q771 192-5886-00 2SC5886
Q772 192-4155-51 2SC4155A S,T
Q773 192-4155-51 2SC4155A S,T
Q774 192-4155-51 2SC4155A S,T
Q775 192-4155-51 2SC4155A S,T
Q776 125-0034-92 RT1P141M
Q777 125-2041-92 RT1N141M
Q821 190-2071-00 2SA2071 T100
Q822 192-4155-51 2SC4155A S,T
R101 119-0000-05 1/10W 0 ohm JW
R102 119-0000-05 1/10W 0 ohm JW
R103 119-1041-15 1/10W 100k ohm
R104 119-0000-05 1/10W 0 ohm JW
R105 119-4711-15 1/10W 470 ohm
R106 119-2221-15 1/10W 2.2k ohm
R107 116-1001-15 1/4W 10 ohm
R108 119-2231-15 1/10W 22k ohm
R109 119-4731-15 1/10W 47k ohm
R111 119-0000-05 1/10W 0 ohm JW
(PS-3025K-A)
166-8201-50 82pF CH
(PS-3025K-B)
R122 119-2221-15 1/10W 2.2k ohm
R125 119-1021-15 1/10W 1k ohm
R127 119-5631-15 1/10W 56k ohm
R128 119-4731-15 1/10W 47k ohm
R130 119-2221-15 1/10W 2.2k ohm
R131 119-1031-15 1/10W 10k ohm
R132 119-1031-15 1/10W 10k ohm
R133 119-2221-15 1/10W 2.2k ohm
R134 119-2221-15 1/10W 2.2k ohm
R135 119-1031-15 1/10W 10k ohm
R151 119-1021-15 1/10W 1k ohm
R152 119-5621-15 1/10W 5.6k ohm
R153 119-3311-15 1/10W 330 ohm
R154 119-1021-15 1/10W 1k ohm
R155 119-3331-15 1/10W 33k ohm
R156 119-1031-15 1/10W 10k ohm
R157 119-1231-15 1/10W 12k ohm
R158 119-3321-15 1/10W 3.3k ohm
R159 119-1041-15 1/10W 100k ohm
R160 119-2211-15 1/10W 220 ohm
R161 119-0000-05 1/10W 0 ohm JW
R162 119-1021-15 1/10W 1k ohm
R163 119-1021-15 1/10W 1k ohm
R164 119-2221-15 1/10W 2.2k ohm
R165 119-5631-15 1/10W 56k ohm
R166 119-1231-15 1/10W 12k ohm
R167 116-3311-15 1/4W 330 ohm
R168 119-1031-15 1/10W 10k ohm
R169 119-2711-15 1/10W 270 ohm
R170 119-1021-15 1/10W 1k ohm
R171 119-0000-05 1/10W 0 ohm JW
R172 119-1021-15 1/10W 1k ohm
R173 119-1031-15 1/10W 10k ohm
R242 119-4731-15 1/10W 47k ohm
R243 119-1021-15 1/10W 1k ohm
R245 119-3331-15 1/10W 33k ohm
R246 119-4731-15 1/10W 47k ohm
R248 119-1041-15 1/10W 100k ohm
R250 119-3331-15 1/10W 33k ohm
R253 119-4731-15 1/10W 47k ohm
R255 119-3331-15 1/10W 33k ohm
R256 119-0000-05 1/10W 0 ohm JW
