PS-3025K-A,B
- 10 -
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
TH711 002-0318-21 THERMISTOR
TM101 073-0762-90 TERMINAL
TM501 073-0762-90 TERMINAL
TM502 073-0762-90 TERMINAL
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
TM801 073-0762-90 TERMINAL
TM802 073-0762-90 TERMINAL
X121 061-1066-00 CRYSTAL 7.2MHZ
X151 061-3013-00 CRYSTAL 4.332MHZ
X501 060-1533-90 CSTCE10M0G52-
RO
PWB 039-3108-00 PWB(WITHOUT
COMPONENT)
C100 168-1042-78 16V 0.1uF
C101 168-1042-78 16V 0.1uF
C102 168-1042-78 16V 0.1uF
C103 168-1042-78 16V 0.1uF
C104 168-1042-78 16V 0.1uF
C105 178-1052-78 1uF
D100 001-7048-91 RFR1112H-22 C,D
RED
D101 001-7048-91 RFR1112H-22 C,D
RED
D102 001-7048-91 RFR1112H-22 C,D
RED
D103 001-7048-91 RFR1112H-22 C,D
RED
D104 001-7087-90 RBR1112H C,D,E
RED
D105 001-7048-91 RFR1112H-22 C,D
RED
D106 001-7048-91 RFR1112H-22 C,D
RED
D107 001-7048-91 RFR1112H-22 C,D
RED
D108 001-7048-91 RFR1112H-22 C,D
RED
D113 001-0580-90 1SS352
D114 001-0580-90 1SS352
D115 001-0580-90 1SS352
D116 001-0580-90 1SS352
IC100 051-6084-00 NJU6625FG1-03
J100 074-3013-74 24P
L100 010-3406-66 22uH J
LCD100 379-1363-51 INDICATOR(LCD)
PL100 017-0420-43 14V 40mA RED
PL101 017-0420-43 14V 40mA RED
PL102 017-0420-43 14V 40mA RED
PL104 017-0420-43 14V 40mA RED
PL105 017-0420-43 14V 40mA RED
PL106 017-0420-43 14V 40mA RED
PL107 017-0420-43 14V 40mA RED
PL108 017-0420-43 14V 40mA RED
PL109 017-0420-43 14V 40mA RED
PL110 017-0420-43 14V 40mA RED
PL111 017-0420-43 14V 40mA RED
R100 119-1521-15 1/10W 1.5k ohm
R101 119-1221-15 1/10W 1.2k ohm
R102 119-1221-15 1/10W 1.2k ohm
R103 119-1521-15 1/10W 1.5k ohm
R104 119-1221-15 1/10W 1.2k ohm
R105 119-1221-15 1/10W 1.2k ohm
R106 119-1521-15 1/10W 1.5k ohm
R107 119-1221-15 1/10W 1.2k ohm
R108 119-1221-15 1/10W 1.2k ohm
R109 119-1521-15 1/10W 1.5k ohm
R110 119-1221-15 1/10W 1.2k ohm
R111 119-1221-15 1/10W 1.2k ohm
R112 119-2221-15 1/10W 2.2k ohm
R113 119-2221-15 1/10W 2.2k ohm
R114 119-1821-15 1/10W 1.8k ohm
R116 119-0000-05 1/10W 0 ohm JW
R117 119-0000-05 1/10W 0 ohm JW
R121 119-4341-15 1/10W 430k ohm
R122 119-0000-05 1/10W 0 ohm JW
R123 119-0000-05 1/10W 0 ohm JW
R125 119-0000-05 1/10W 0 ohm JW
R126 119-0000-05 1/10W 0 ohm JW
R128 119-1021-15 1/10W 1k ohm
R129 119-1021-15 1/10W 1k ohm
R131 119-0000-05 1/10W 0 ohm JW
R132 119-0000-05 1/10W 0 ohm JW
R140 119-0000-05 1/10W 0 ohm JW
R200 119-1841-15 1/10W 180k ohm
R201 119-1841-15 1/10W 180k ohm
R202 119-1841-15 1/10W 180k ohm
R203 119-1841-15 1/10W 180k ohm
TH100 002-0306-90 SC20-3J153
TM100 073-0778-90 TERMINAL
VR100 016-0014-12 VR W/SHAFT
VR101 016-0014-12 VR W/SHAFT
PWB 039-3035-00 PWB(WITHOUT
COMPONENT)
Switch PWB section (B2)
