Clarion PS-3025K-A User Manual

- M11 -
929-0374-81
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ELECTRICAL PARTS LIST
CD PWB(BM1) section
C1 042-0672-00 25V 47uF TA
C2 166-1011-50 100pF CH
C3 168-1042-78 16V 0.1uF
C4 178-1052-78 1uF
C5 042-0671-01 10V 47uF TA
C6 168-1042-78 16V 0.1uF
C7 168-1032-55 0.01uF K
C8 168-1042-78 16V 0.1uF
C9 178-1052-78 1uF
C10 168-1042-78 16V 0.1uF
C11 168-1042-78 16V 0.1uF
C12 178-1052-78 1uF
C13 178-1052-78 1uF
C14 042-0671-01 10V 47uF TA
C15 168-1032-55 0.01uF K
C20 178-1052-78 1uF
C21 168-1042-78 16V 0.1uF
C22 178-1052-78 1uF
C23 168-1042-78 16V 0.1uF
C24 042-0671-01 10V 47uF TA
C25 168-1042-78 16V 0.1uF
C26 168-1045-56 0.1uF Z
C27 168-4732-78 0.047uF K
C28 166-4701-50 47pF CH
C29 168-4732-78 0.047uF K
C30 166-4711-50 470pF CH
C31 168-1532-55 0.015uF K
C32 166-4711-50 470pF CH
C33 168-1042-78 16V 0.1uF
C34 168-6822-55 6800pF K
C35 168-1032-55 0.01uF K
C38 168-3332-78 0.033uF K
C39 168-4722-55 4700pF K
C40 168-1042-78 16V 0.1uF
C42 168-1042-78 16V 0.1uF
C43 168-1532-55 0.015uF K
C44 168-1042-78 16V 0.1uF
C45 168-1522-55 1500pF K
C46 168-1042-78 16V 0.1uF
C47 166-6811-50 680pF
C48 166-6801-50 68pF CH
C49 178-1052-78 1uF
C50 042-0671-01 10V 47uF TA
C51 042-0671-01 10V 47uF TA
C52 178-1052-78 1uF
C53 168-1042-78 16V 0.1uF
C54 178-1052-78 1uF
C55 178-1052-78 1uF
C56 042-0671-01 10V 47uF TA
C57 168-1042-78 16V 0.1uF
C59 168-1042-78 16V 0.1uF
C60 178-1052-78 1uF
C61 168-1032-55 0.01uF K
C62 168-1042-78 16V 0.1uF
C63 168-1042-78 16V 0.1uF
C64 168-1042-78 16V 0.1uF
C65 168-1042-78 16V 0.1uF
C66 168-1042-78 16V 0.1uF
C67 168-1042-78 16V 0.1uF
C68 168-1042-78 16V 0.1uF
C70 168-1042-78 16V 0.1uF
C71 168-1042-78 16V 0.1uF
C72 168-1042-78 16V 0.1uF
C73 178-1052-78 1uF
C74 168-1042-78 16V 0.1uF
C75 168-2222-55 2200pF K
C81 166-1007-50 10pF CH
C82 166-1007-50 10pF CH
C83 178-1052-78 1uF
C85 178-1052-78 1uF
C86 166-1201-50 12pF CH
C87 042-1702-90 6.3V 100uF
C91 168-1032-55 0.01uF K
CCT1 050-0145-59 1/16W 22 ohm x4
CCT2 050-0145-54 1/16W 47k ohm x4
CCT3 050-0145-54 1/16W 47k ohm x4
CCT4 050-0145-55 1/16W 10k ohm x4
D1 001-4301-14 HZU 3.0B1
D1 001-0529-14 MA8030-L
D2 001-0367-91 1SS226
D3 001-4301-16 HZU 3.3B1
D3 001-0529-16 MA8033-L
D4 001-4301-18 HZU 3.6B1
D4 001-0529-18 MA8036-L
IC1 051-6399-00 TC94A15F
IC2 052-5070-20 TMP91CY22IFG-
6NH7
IC3 051-6711-20 TC94A34FG-004
IC4 051-6060-08 BD7961FM-E2
IC5 051-5452-90 BD5235G-TR
IC6 051-9318-10 GLT4160L04P-60TC
IC6 051-9318-00 MSM51V17400J-60T
IC8 051-9402-78 BR93L56RFVM-W
IC9 051-6072-08 BD7931FE2
IC10 051-5833-00 GP1S093HCZ
IC11 051-3364-90 NJU7771F15
IC12 051-3364-90 NJU7771F15
J1 074-1237-69 19PIN
J2 074-1201-65 15P
J3 074-1138-56 6P
J4 074-1100-61 SOCKET 11P
J5 074-1201-61 11P SOCKET
Q1 060-0252-01 PT4850F
Q2 125-0021-91 DTA114EUA
Q3 198-3018-00 2SK3018
Q6 131-1188-50 2SB1188PQR
Q7 125-2027-91 DTC114EUA
Q8 131-1427-00 2SB1427
Q9 131-1188-50 2SB1188PQR
Q10 125-2027-91 DTC114EUA
Q11 125-0021-91 DTA114EUA
Q12 125-2027-91 DTC114EUA
Q20 131-1427-00 2SB1427
R1 119-4731-15 1/10W 47k ohm
R2 119-2211-15 1/10W 220 ohm
R3 119-2211-15 1/10W 220 ohm
R4 119-1041-15 1/10W 100k ohm
R5 119-4731-15 1/10W 47k ohm
R6 119-2211-15 1/10W 220 ohm
R7 119-2211-15 1/10W 220 ohm
R8 119-2211-15 1/10W 220 ohm
R10 032-0140-16 1/10W 180k ohm F
R11 032-0140-96 1/10W 120k ohm F
R12 119-2231-15 1/10W 22k ohm
R13 119-4711-15 1/10W 470 ohm
R14 119-2221-15 1/10W 2.2k ohm
R15 119-1031-15 1/10W 10k ohm
R16 119-0000-05 1/10W 0 ohm JW
R17 119-4731-15 1/10W 47k ohm
R18 119-2231-15 1/10W 22k ohm
R19 119-2231-15 1/10W 22k ohm
R20 119-4721-15 1/10W 4.7k ohm
R21 119-4731-15 1/10W 47k ohm
R22 119-4731-15 1/10W 47k ohm
R23 119-4731-15 1/10W 47k ohm
R24 050-0145-58 1/16W 2.2k ohm x4
R25 119-4721-15 1/10W 4.7k ohm
R26 119-4721-15 1/10W 4.7k ohm
R27 117-7511-15 1/8W 750 ohm
R28 116-3391-15 1/4W 3.3 ohm
R29 032-0145-73 1/2W 6.8 ohm
R30 119-1041-15 1/10W 100k ohm
R31 119-6811-15 1/10W 680 ohm
R32 119-1041-15 1/10W 100k ohm
R33 119-6811-15 1/10W 680 ohm
R34 119-1041-15 1/10W 100k ohm
R35 117-5611-15 1/8W 560 ohm
R36 119-1041-15 1/10W 100k ohm
R37 119-1041-15 1/10W 100k ohm
R38 119-3321-15 1/10W 3.3k ohm
R39 119-1051-15 1/10W 1M ohm
R40 119-0000-05 1/10W 0 ohm JW
R41 119-1041-15 1/10W 100k ohm
R42 119-5621-15 1/10W 5.6k ohm
R43 119-4731-15 1/10W 47k ohm
R44 119-2231-15 1/10W 22k ohm
R45 119-8231-15 1/10W 82k ohm
R46 119-3341-15 1/10W 330k ohm
R48 119-2231-15 1/10W 22k ohm
R49 116-1001-15 1/4W 10 ohm
R50 119-1011-15 1/10W 100 ohm
R51 119-6811-15 1/10W 680 ohm
R52 117-7511-15 1/8W 750 ohm
R53 116-5611-15 1/4W 560 ohm
R54 119-1041-15 1/10W 100k ohm
R55 119-1041-15 1/10W 100k ohm
R56 119-1041-15 1/10W 100k ohm
R57 119-1041-15 1/10W 100k ohm
R58 119-1041-15 1/10W 100k ohm
R59 116-1511-15 1/4W 150 ohm
R60 119-4731-15 1/10W 47k ohm
R61 119-4731-15 1/10W 47k ohm
R62 119-1051-15 1/10W 1M ohm
R64 032-0140-62 1/10W 1.0k ohm F
R65 119-2211-15 1/10W 220 ohm
R66 032-0140-53 1/10W 2.2k ohm F
R71 119-1011-15 1/10W 100 ohm
R72 119-1011-15 1/10W 100 ohm
R73 119-1011-15 1/10W 100 ohm
R77 119-0000-05 1/10W 0 ohm JW
R82 119-1011-15 1/10W 100 ohm
R83 119-1031-15 1/10W 10k ohm
R85 119-1021-15 1/10W 1k ohm
R86 119-2231-15 1/10W 22k ohm
S1 013-7416-50 SW SPVL110200
S2 013-7416-50 SW SPVL110200
S3 013-7416-50 SW SPVL110200
S4 013-7415-50 SPVG110400
X1 061-3534-90 16.92MHz
X3 060-1545-90 20MHz
PWB 039-2747-21 PWB(WITHOUT
COMPONENTS)
Sensor-L-PFC(BM2)
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
PT1 060-0252-01 PT14850F
PT2 060-0252-01 PT14850F
PT3 051-5833-00 GP1S093HCZ
PWB 039-2467-21 PWB(WITHOUT
COMPONENTS)
Sensor-U-PFC(BM3)
LED1 001-7077-00 GL4804
LED2 001-7077-00 GL4804
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
LED3 001-7077-00 GL4804
S5 013-7417-50 ABC1122P161
PWB 039-2466-20 PWB(WITHOUT
COMPONENTS)
C1 042-0672-00 25V 47uF TA
C2 166-1011-50 100pF CH
C3 168-1042-78 16V 0.1uF
C4 178-1052-78 1uF
C5 042-0671-01 10V 47uF TA
C6 168-1042-78 16V 0.1uF
C7 168-1032-55 0.01uF K
C8 168-1042-78 16V 0.1uF
C9 178-1052-78 1uF
C10 168-1042-78 16V 0.1uF
C11 168-1042-78 16V 0.1uF
C12 178-1052-78 1uF
C13 178-1052-78 1uF
C14 042-0671-01 10V 47uF TA
C15 168-1032-55 0.01uF K
C20 178-1052-78 1uF
C21 168-1042-78 16V 0.1uF
C22 178-1052-78 1uF
C23 168-1042-78 16V 0.1uF
C24 042-0671-01 10V 47uF TA
C25 168-1042-78 16V 0.1uF
C26 168-1045-56 0.1uF Z
C27 168-4732-78 0.047uF K
C28 166-4701-50 47pF CH
C29 168-4732-78 0.047uF K
C30 166-4711-50 470pF CH
C31 168-1532-55 0.015uF K
C32 166-4711-50 470pF CH
C33 168-1042-78 16V 0.1uF
C34 168-6822-55 6800pF K
C35 168-1032-55 0.01uF K
C38 168-3332-78 0.033uF K
C39 168-4722-55 4700pF K
C40 168-1042-78 16V 0.1uF
C42 168-1042-78 16V 0.1uF
C43 168-1532-55 0.015uF K
C44 168-1042-78 16V 0.1uF
C45 168-1522-55 1500pF K
C46 168-1042-78 16V 0.1uF
C47 166-6811-50 680pF
C48 166-6801-50 68pF CH
C49 178-1052-78 1uF
C50 042-0671-01 10V 47uF TA
C51 042-0671-01 10V 47uF TA
C52 178-1052-78 1uF
C53 168-1042-78 16V 0.1uF
C54 178-1052-78 1uF
C55 178-1052-78 1uF
C56 042-0671-01 10V 47uF TA
C57 168-1042-78 16V 0.1uF
C59 168-1042-78 16V 0.1uF
C60 178-1052-78 1uF
C61 168-1032-55 0.01uF K
C62 168-1042-78 16V 0.1uF
C63 168-1042-78 16V 0.1uF
C64 168-1042-78 16V 0.1uF
C65 168-1042-78 16V 0.1uF
C66 168-1042-78 16V 0.1uF
C67 168-1042-78 16V 0.1uF
C68 168-1042-78 16V 0.1uF
C70 168-1042-78 16V 0.1uF
C71 168-1042-78 16V 0.1uF
C72 168-1042-78 16V 0.1uF
C73 178-1052-78 1uF
