22
diagnostics
The system’s microprocessor monitors and reports all active and violated zones when arming and dis-
arming. LED flashes indicate the active or violated zone; siren chirps indicate system status.
arm/disarm diagnostics
The number of siren chirps will indicate the status of the system when arming and disarming. For infor-
mation on which zone is active or has been violated refer to the Table of Zones.
system status chirps
table of zones
NNOOTTEE::
The Warning response does not report on the LED.
Zone No. Trigger type Input description
1 Instant H1/6 BLUE wire. Connect to optional hood/trunk
pins.
2 Multiplexed BLUE wire of plug-in shock sensor. Inputs
shorter than 0.8 seconds will trigger a Warning
Zone response, while inputs longer than 0.8
seconds will instantly trigger the full alarm
sequence.
3 Two-stage, progresses from Door switch circuit.H1/5 GREEN or H1/7 VIOLET.
warning to full alarm
4 Multiplexed Input GREEN wire of plug-in shock sensor. Inputs
shorter than 0.8 seconds will trigger a Warning
Zone response, while inputs longer than 0.8
seconds will instantly trigger the full alarm
sequence.
5 Two-stage (similar to doors) Ignition input. H1/9 YELLOW.
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3 second delay), 1 System armed with an open zone(s) bypassed
Disarm 2 System disarmed
Disarm 4 System disarmed with tamper alert
Disarm 5 System disarmed false alarm prevention active
