Section 4. Operating Procedures
4.34.3
Emergency Reversal Switch
Emergency Reversal Switch • Lift/Lower Contol
Emergency
Reversal Switch
When the emergency reversal switch strikes an object or a person, or
is held in by the operator, the truck automatically propels itself in the
"reverse" direction ("Reverse" is dened as traveling with the forks
leading). When the switch no longer contacts the person or object,
the switch pops up and the truck resumes normal control. Emergency
reversal is disabled when the brake is "On".
CAUTION
Be careful not to activate Emergency Reversal Switch
when pulling down the handle from the parked position.
Lift, Lower, and Horn Control
Lift /Lower Control
• Press the "lift" control to raise the load forks.
• Press the "lower" control to lower the load forks.
• Press Horn button to sound horn
