Clarke C18 User Manual

49
List of Diagnostic Trouble Codes
SPN
FMI
Description
28
3
Throttle #3 Input High
28
4
Throttle #3 Input Low
29
3
Throttle #2 Input High
29
4
Throttle #2 Input Low
91
3
Throttle #1 Input High
91
4
Throttle #1 Input Low
91
8
PWM Throttle Abnormal Pulse Width
91
9
Throttle Invalid
91
14
Throttle Voltage Out of Range
94
1
Fuel Supply Pressure Extremely Low
94
3
Fuel Supply Pressure Input Voltage High
94
4
Fuel Supply Pressure Input Voltage Low
94
16/31
Fuel Supply Pressure Moderately High
94
18
Fuel Supply Pressure Moderately Low
97
0
Water in Fuel – Continuously Detected
97
3
Water in Fuel Signal – Voltage High
97
4
Water in Fuel Signal – Voltage Low
97
16
Water in Fuel Detected
100
1
Engine Oil Pressure Extremely Low
100
3
Engine Oil Pressure Input Voltage High
100
4
Engine Oil Pressure Input Voltage Low
100
18
Engine Oil Pressure Moderately Low
102
3
Manifold Air Pressure Input Voltage High
102
4
Manifold Air Temperature Input Voltage Low
105
3
Manifold Air Temperature Input Voltage High
105
4
Manifold Air Temperature Input Voltage Low
105
16
Manifold Air Temperature Input Voltage High
110
0
Engine Coolant Temperature Extremely High
110
3
Engine Coolant Temperature Input Voltage
High
110
4
Engine Coolant Temperature Input Voltage
Low
110
16
Engine Coolant Temperature Moderately High
111
1
Engine Coolant Level Low
158
17
ECM Power Down Error
174
3
Fuel Temperature Input Voltage High
174
4
Fuel Temperature Input Voltage Low
611
3
Injector Shorted to Power Source
611
4
Injector Wiring Shorted to Ground
620
3
Sensor Supply Voltage High
620
4
Sensor Supply Voltage Low
627
1
Injector Supply Voltage Problem
629
12/13
ECM Error
636
2
Cam Position Input Noise
636
8
Cam Position Input Missing
636
10
Cam Position Input Pattern Error
637
2
Cam Position Input Noise
637
8
Cam Position Input Missing
637
7
Crank Position/Cam Position Out of Sync
637
10
Crank Position Input Pattern Error
651
5
Cylinder #1 EUI Circuit Open
651
6
Cylinder #1 EUI Circuit Shorted
652
5
Cylinder #2 EUI Circuit Open
652
6
Cylinder #2 EUI Circuit Shorted
653
6
Cylinder #3 EUI Circuit Open
653
5
Cylinder #3 EUI Circuit Shorted
654
6
Cylinder #4 EUI Circuit Open
654
5
Cylinder #4 EUI Circuit Shorted
655
6
Cylinder #5 EUI Circuit Open
655
5
Cylinder #5 EUI Circuit Shorted
656
5
Cylinder #6 EUI Circuit Open
656
6
Cylinder #6 EUI Circuit Shorted
970
2
Auxiliary Engine Shutdown Switch Signal
Invalid
970
31
Auxiliary Engine Shutdown Switch Active
971
31
External Fuel De-Rate Switch Active
1109
31
Engine Shutdown Warning
1110
31
Engine Shutdown
1569
31
Fuel De-rate
2000
13
Security Violation
3133
4
PLD Transducer – under 13 psi
NOTE: The PowerView diagnostic gauge can have communication problems that result in Error Codes being shown on
its LCD display window. The following Error Codes all indicate that there is a Diagnostic Gauge communication error
with the ECM. Contact your servicing dealer for help in correcting these codes:
EE – Error XXXXX – EP
No Data
ACP – Err XXXXX - BO
No Addr No Data
ACP – Err XXXXX - BR
BUS – EP No Data
NOTE: Refer to wiring diagnostic earlier in this section as a guide to connections and wires.
