06-12
15
Clean Track
®
16 / 18 / 18 Wash & Rinse
FORM NO. 56041660
Item Ref. No. Qty Description
1 56244866 1 Cap, Raw (Clean Track 18 Wash & Rinse)
2 56453849 1 Bushing .26x.37x.28 (Clean Track 18 Wash & Rinse)
3 56692409 1 Cover Chain
4 56832322 1 Cover-Solution Tank
5 1 Wsh, Flt SAE #10 (Clean Track 18 Wash & Rinse)
6 6 Scr, Pan Phil 10-24 X .62
7 1 Scr, Pan Phil 10-24 X .75 (Clean Track 18 Wash & Rinse)
8 1 Nut, Hex Nyl Loc SS 10-24
9 1 Scr, Pan Phil SS 10-24 X .50
10 1 Scr, Pan Phil Type A 10 X .50
11 56003753 1 Stud, 1/4-20 X 1.75 (Clean Track 18 Wash & Rinse)
12 1 Wsh, Flt SS .260 X 1.000 X .074 (Clean Track 18 Wash & Rinse)
13 56009111 1 Nut, Wing SS 1/4-20 (Clean Track 18 Wash & Rinse)
14 3 Clamp, Hose SAE #6
15 56262190 1 Barb
16 56264137 1 Screen
17# 56265096 1 Vac Motor, 120V (M1 / 115V)
* 56264453 1 Carbon Brush (set of 2) NOTE 1
# 56265117 1 Vac Motor, 230V (M1 / 230V)
*# 56264452 1 Carbon Brush (set of 2) NOTE 2
18 56265202 1 Vac Hose Assy
19 56265216 1 Hose, Pvc Clear 11.00
20 56266017 1 Tank, Solution, 16”
56266019 1 Tank, Solution, 18”
21 56266023 1 Chemical Tank Assembly (Clean Track 18 Wash & Rinse)
22 56266053 1 38 Mm Cap Assy, 90 X 1/4 Barb (Clean Track 18 Wash & Rinse)
23 56266056 1 Gasket, RS Strip (16”)
56266057 1 Gasket, RS Strip (18”)
24 56266058 1 Gasket, RS Strip
25 56266069 1 Lower Recovery Hose Assembly
26 56266072 1 Ergoex Belt Bracket
27 56266073 2 Grommet, Drain
28 56266094 1 Vacuum Motor Gasket
29 56314484 3 Mount, Vibration
30 56314617 1 Latch, Plastic (Clean Track 18 Wash & Rinse)
31 56314760 1 Gasket, Vacuum Duct
32 56331154 3 Clamp, Plastic
33 56386183 2 Barbed Elbow 90
34# 56266134 1 Hose, Spiral .50 x 22.00
35 1 Clamp, Hose SAE #32
36 61088a 1 Ergoex Belt
** 11147A 1 Kit, Solution Tank Assy Hardware
# = Revised or new since last update
* = Not Shown
** = Optional, Not Included
NOTE 1: Replacement parts for 56265096
NOTE 2: Replacement parts for 56265117
SOLUTION TANK ASSEMBLY
07-10
