Clarke EZ-8 User Manual

Page 6 Clarke
®
American Sanders EZ - 8 Sander Operator's Manual
How to Transport the Machine
Transporting the Machine With Limited
Cargo Area:
To transport the machine, follow this procedure:
1. Lower sanding drum with control lever. See
figure 1.
2. Slide collar beyond overlap of control link; remove
pin from notch. See figure 2.
3. Twist and remove handle pigtail from motor cord.
See figure 3.
4. Release handle latches and remove handle from
chassis. See figure 2.
5. Remove dust pipe from chassis.
6. Lift chassis with transport handles and place in
cargo area. See figure 4.
WARNING: Machine is heavy (43.2kg). To
avoid injury or damage grasp
transport handles firmly; use
proper lifting technique.
7. Secure chassis to prevent movement in cargo area.
Place handle and dust pipe in cargo area.
Figure 2
Figure 3
Figure 1
Figure 4
