Clarke Metalworker CL430 User Manual

5
SPECIFICATIONS
LATHE
Motor .................................................................... 230VAC, 50Hz, 1 Phase
Power Rating ............................................... 3/4HP
Fuse Rating .................................................. 13Amps
Distance Between Centres ................................. 430mm
Centre Height....................................................... 150mm
Max. Work Diameter over Bed ........................... 305mm
Max. Work Diameter over Cross Slide ............... 172mm
Spindle Bore ......................................................... 26mm
Spindle Taper ....................................................... No.4 MT
Tailstock Taper ..................................................... No.3 MT
Spindle Speeds .................................................... 6 (170 to 1630 RPM)
Overall Dimensions (LxWxH) .............................. 1100x600x405mm
Overall Dimensions with Mill Drill attached ....... 1100x600x880mm
Weight................................................................... 129kg
Weight with Mill Drill attached ............................ 164kg
Screw Threads - Imperial .................................... 20 (11 - 40 TPI)
Metric ....................................... 14 (0.5 - 3.0mm pitch)
MILL DRILL
Drill capacity ....................................................... 13mm
Spindle Column ................................................... 175mm
Spindle Nose to Table ......................................... 150 - 320mm
Spindle to Bed ...................................................... 212 - 382mm
Spindle Stroke ...................................................... 92mm
Spindle Taper ....................................................... No.3 MT (with Draw Bar)
Spindle Speeds .................................................... 12 (130 - 1660)
Table Size.............................................................. 200x150mm
T-Slots .................................................................... 12mm
CL430 Part No. ...................................................... 7610800
CL500M Part No. .................................................. 7610300
Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve
the right to change specifications at any time without prior notice.
