Clarke MIG151TE - Page 25

25
Workpiece
Thickness
(mm)
Welding
Position
Wire Speed
Adjustment
Welding
Position
Wire Speed
Adjustment
0.6 mm Gas Welding Wire 0.8 mm Gas Welding Wire
AB C AB C
0.6 - 0.8 MIN 1 5-6 MIN 1 5-6
0.8 - 1.0 MIN 2 5-6 MIN 2 5-6
1.0 - 1.2 MIN 3 5-6 MIN 3 6
1.2 - 2.0 MAX 1 6 MAX 1 6
2.0 - 3.0 MAX 2 7 MAX 2 7
>3.0 MAX 3 7-8 MAX 3 7-8
STEEL
AB C
0.9 MIN 1 5-6
0.9 - 1.0 MIN 2 5-6
1.0 - 1.2 MIN 3 5-6
1.2 - 2.0 MAX 1 6
2.0 - 3.0 MAX 2 7
>3.0 MAX 3 7-8
AB C
1.0 - 1.5 MIN 1 9
1.5 - 2.0 MIN 2 9
2.0 - 2.5 MIN 3 9
2.5 - 3.0 MAX 1 9
>3.0 MAX 2/3 10
Workpiece
Thickness
(mm)
Welding
Position
Wire Speed
Adjustment
0.8 mm Gas Welding Wire
ALUMINIUM
CONTROL SETTINGS - REFERENCE TABLES
B. MIGs 151TE & 160EN
Workpiece
Thickness
(mm)
Welding
Position
Wire Speed
Adjustment
0.9 mm Gas Welding Wire
SOFT STEEL
NO GAS
