PARTS LIST
No Description No Description
01 Switch 24 Fuel Valve
02 Panel 25 Fuel Tank
03 Voltmeter 26 Frame
04 230V/32A Socket 27 Cross Beam
05 AC Breaker 28 Bolt M6x40
06 Screw M3x8 29 Gasket 6
07 115V/32A Socket 30 Flange Nut M6
08 115V/16A Socket 31 Handle
09 Earth Bolt 32 Anti Vibration Foot
10 Bolt M4x12 33 Supporting feet
11 Bolt M6x12 34 Rubber Feet
12 Panel Back Cover 35 Flange Nut M12
13 Wiring Loom 36 Plastic Wheels
14 Voltage Switch 37 Battery
15 Generator 38 Shaft Fixed Bracket
16 Engine 39 Flange Bolt M8x16
17 Rubber Gasket 40 Flange Nut M8
18 Washer 41 Long Shaft
19 Bolt M6x25 42 Back Guard Plate
20 Fuel Filler Cap 43 Flange Bolt M6x12
21 Fuel Filter 44 Side Guard Plate
22 Screw M5x12 45 Flange Bolt M6x35
23 Fuel Gauge 46 Curved Plate
