THE HIGH PRESSURE HOSE
CONNECT THE HOSE TO THE GUN
1.
Slide the connector on the hose
backwards.
2. Push the gun into the connector.
3. Release the connector.
NOTE: Mak
e sure the connection is
secure.
CONNECT THE HOSE TO THE POWER WASHER
1.
Slide the connector on the power
washer towards the machine.
2. Push the hose into the connector.
3. Release the connector.
NOTE: Mak
e sure the connection is
secure.
CONNECT WATER INLET HOSE
1. Remove the travel cap if fitted.
2. Connect the water supply hose to
the water
inlet.
NOTE: Water source must provide
a minimum of 5 gallons per
minute.
NOTE: Make sure the water inlet
hose is screwed on tightly.
HOSE / LANCE STORAGE BRACKET
1. Fit the bracket into the position
shown and secure using the
washers and nuts supplied
To Next Page
