Clarke Power Wash PLS195A User Manual

Clarke Power Wash PLS195A

28 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

OPERATION & MAINTENANCE

INSTRUCTIONS

LS0919 ISS 1

PETROL POWER WASHER

MODEL NO: PLS195A

PART NO: 7330361

Questions and Answers:

M
Mary DrakeAug 14, 2025
Why won't my Clarke Pressure Washer engine start?
- T
  Troy DavisAug 14, 2025
  Your Clarke Pressure Washer engine might not start due to several reasons: there may be no fuel, so add fuel; the oil level might be low, so add oil; the spark plug wire may not be correctly attached, so attach the spark plug wire; the engine switch may be in the OFF position, so set it to the ON position; the choke lever may be set to the choke position when the engine is warm, so set it to the NO CHOKE position; the fuel valve may be closed, so open the fuel valve; or pressure builds up after two pulls, so squeeze the gun trigger to relieve the pressure.
J
julia96Aug 17, 2025
What to do if my Clarke Power Wash PLS195A Pressure Washer has no pressure on initial use?
- C
  Chelsea DunnAug 17, 2025
  If your Clarke Pressure Washer lacks pressure upon initial use, it could be due to several reasons. Ensure your water supply can deliver 5 gallons per minute at 20psi. Check for leaks in the high-pressure hose fitting, and tighten it, using sealant tape if needed. Clear any obstructions from the nozzle and remove and clean the water filter screen if it's clogged. Also, if there is air in the supply hose, turn off the engine and water supply, disconnect the water supply from the pump inlet, and turn on the water to expel the air. Reconnect the hose, turn on the water supply, and pull the trigger to expel any air in the gun/wand.
G
gdavisAug 20, 2025
What to do if my Clarke Power Wash PLS195A has no or low pressure after normal use?
- J
  Jennifer StokesAug 20, 2025
  If your Clarke Pressure Washer has no or low pressure after a period of normal use, have the worn seal, worn or obstructed valves, worn unloader piston, or worn E-Z start valve replaced by your dealer.
M
moyersusanAug 25, 2025
Why Clarke Power Wash PLS195A won't draw detergent?
- X
  xnixonAug 25, 2025
  If your Clarke Pressure Washer won't draw detergents, the chemical filter might be blocked, so clean the filter. The chemicals being used might be too thick, so dilute them to the consistency of water. If the high pressure hose is too long, use a longer supply hose instead. If there is chemical build up inside the chemical injector, have the parts cleaned or replaced by your dealer.
J
John GutierrezAug 27, 2025
What to do if Clarke Pressure Washer has lack of pressure (initial use) continued?
- R
  ryan18Aug 27, 2025
  If your Clarke Pressure Washer continues to lack pressure after initial use, make sure the throttle control lever is in the fast position and the choke lever is in the NO CHOKE position. Also, ensure the high-pressure hose is under 100 feet.
L
Lori PaceAug 30, 2025
What causes water leaking at the pump of my Clarke Pressure Washer?
- A
  Amber RobinsonAug 30, 2025
  If water is leaking at the pump of your Clarke Pressure Washer, check for loose connections and tighten them. If the piston packings are worn, or there is a worn or broken O-ring, or if the pump head or tubes are damaged from freezing, have it replaced by your dealer.
M
Megan McgeeSep 3, 2025
How to fix water leaking at the gun / spray wand connection of my Clarke Power Wash PLS195A Pressure Washer?
- J
  Jessica PayneSep 3, 2025
  If water is leaking at the gun or spray wand connection of your Clarke Pressure Washer, check for a worn or broken O-ring and replace it. Also, ensure the hose connection is not loose and tighten it if necessary.
L
Lisa MaxwellSep 6, 2025
Why does my Clarke Power Wash PLS195A pump pulsate?
- M
  Michael GrantSep 6, 2025
  If your Clarke Pressure Washer pump pulsates, it is likely that the nozzle is obstructed. Clear the nozzle to resolve this issue.
A
Anthony MoranSep 10, 2025
What causes oil leaking at the pump of my Clarke Power Wash PLS195A?
- S
  Sarah McdonaldSep 10, 2025
  If oil is leaking at the pump of your Clarke Pressure Washer, have the oil seals replaced by your dealer. Check for a loose drain plug and tighten it. Also, inspect the O-rings for wear and replace them if necessary.

Clarke Power Wash PLS195A Specifications

General

Brand	Clarke
Model	Power Wash PLS195A
Category	Pressure Washer
Language	English

Summary

GENERAL SAFETY RULES

SAFETY SYMBOLS

OVERVIEW

ASSEMBLY

FITTING THE WHEELS

Instructions for attaching the wheels to the power washer frame.

THE HIGH PRESSURE HOSE

CONNECT HOSE TO GUN

Guide for connecting the high-pressure hose to the spray gun.

CONNECT HOSE TO POWER WASHER

CONNECT WATER INLET HOSE

BEFORE USE

CHECK PUMP OIL LEVEL

How to check and top up the pump's oil level.

CHECK ENGINE OIL LEVEL

Guide to checking and filling the engine oil.

CHECKING THE FUEL LEVEL

RECOMMENDED FUEL

PRESSURE REGULATOR

SAFETY FEATURES

BYPASS MODE OPERATION

THERMAL RELIEF VALVE FUNCTION

STARTING YOUR POWER WASHER

USING THE POWER WASHER

OPERATING THE GUN AND TRIGGER

ADJUSTING THE SPRAY

NOZZLE SPRAY PATTERN ADJUSTMENT

ADJUSTING THE PRESSURE

METHODS FOR PRESSURE ADJUSTMENT

Details four methods for adjusting water pressure.

APPLYING DETERGENTS AND SOLVENTS

CONNECTING DETERGENT HOSE

SHUTTING DOWN

FLUSHING DETERGENT SYSTEM

POWERING OFF AND SECURING

POWERING OFF THE UNIT

WATER BUTT CONNECTION

CONNECTING TO NON-PRESSURISED WATER

MAINTENANCE

CHANGING THE PUMP OIL

Instructions for changing pump oil after initial use and periodically.

CLEANING PROCEDURES

CLEANING THE NOZZLE

How to clear blockages from the nozzle.

CLEANING THE WATER INLET FILTER

CHANGING THE SPARK PLUG

CHECKING THE AIR FILTER

STORAGE

LONG-TERM STORAGE PROCEDURE

PREPARING FOR EXTENDED STORAGE

TROUBLESHOOTING

SPECIFICATIONS
