14
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
SPECIFICATION
COMPONENT PARTS - GENERAL
Item Spec
Product dimensions (L x W x H) 470 x 375 x 400 mm
Product Weight (kgs) 23.3 kg
Water classification Clean/Dirty
Max solids in suspension 4 mm
Inlet/Outlet Size 2” BSP
Maximum Rated Flow
550 l/min (33m
3
/h)
Max Head 30.6 m
Suction Head 7 m
Max Pressure (Rated) 0.25 MPa (2.5 bar)
Run time @75% rated load 2.65 hrs
Engine type/speed 6.15HP (4 stroke) 3600rpm
Fuel tank capacity (petrol) 3.6 L
Lubrication oil capacity/grade 0.6 L (SAE 15W40)
Sound Pressure Level 90.89 dB LpA
Sound Power Level 103 dB LWA
Guaranteed sound power level 106 dB LWA
Uncertainty Factor (K) 3 dB
