OPERATION & MAINTENANCE
INSTRUCTIONS
ORIGINAL INSTRUCTIONS GC0819 - ISS 1
PETROL ENGINE DRIVEN 2” PUMP
MODEL NO: PW50A
PART NO: 7140651

Table of Contents

Questions and Answers

  • M
    Michael PerezAug 6, 2025
    What to do if Clarke Water Pump fails to prime?
    • J
      Jonathan OwensAug 7, 2025
      If your Clarke Water Pump isn't priming, check the following: * Ensure the priming chamber is completely filled, leaving no air gap. * Inspect the suction line joints for air leaks due to damage, broken clamps, or ill-fitting gaskets; repair as needed. * Check for blockages in the inlet hose. Clean the strainer and ensure it's not submerged in mud or sediment. Also, make sure there are no kinks in the delivery hose. * Increase the engine speed. * The impeller might be damaged. Dismantle the pump and replace the impeller. * Air may be leaking through a damaged seal. Replace the seal.
  • K
    Kerry HudsonAug 13, 2025
    How to fix low output from Clarke Water Pump?
    • T
      Todd MooreAug 14, 2025
      If your Clarke Water Pump has low output, consider these solutions: * Increase the engine speed. * Clean the strainer and ensure it is not submerged in mud or sediment. * Clear any obstructions in the pickup or delivery hose and ensure there are no kinks. * Avoid unnecessary curves, restrictions, or valves in long inlet hoses to reduce frictional losses. * Position the pump as close as possible to the water level. * Dismantle the pump and clean out any congested material inside. * The impeller might be damaged. Dismantle the pump and replace it.
  • W
    william60Aug 21, 2025
    Why won't my Clarke Water Pump engine start?
    • J
      jason69Aug 22, 2025
      There are several reasons why your Clarke Water Pump engine might fail to start: * The fuel tank may be empty. Refill the tank as needed. * Fuel may not be reaching the carburetor. Ensure the fuel tap is turned on. * The engine switch might be in the OFF position. Set the engine switch to the ON position. * There might be a lack of spark at the spark plug. Check that the spark plug cable is securely fitted. If there's still no spark, consult your Clarke dealer.
  • H
    hbutlerAug 28, 2025
    What to do if Clarke Water Pump engine stops and will not re-start?
    • M
      Maria SanchezAug 28, 2025
      If your Clarke Water Pump engine stops and refuses to restart, consider these possibilities: * The fuel tank may be empty. Refill the tank as necessary. * The engine oil level might be too low, triggering the ‘Low Oil Protector’. Top up the oil sump as needed.

Summary

OPERATION & MAINTENANCE INSTRUCTIONS

INTRODUCTION

SAFETY PRECAUTIONS

General Safety Warnings

General warnings about hazards involved with operating the water pump.

SAFETY WHEN USING YOUR PUMP

Safe Operating Practices

Essential safety guidelines for operating the water pump correctly.

Workplace Safety Guidelines

Advice on maintaining a clean, well-lit, and safe working environment.

OVERVIEW

Component Identification

Identifies key components of the petrol engine driven pump with numbered labels.

BEFORE USE

Fitting the Feet

Instructions on how to attach the rubber feet to the pump frame.

Filling with Oil

Guidance on selecting and adding the correct engine oil to the pump.

FILLING WITH FUEL

Refueling Instructions

Procedures for safely refuelling the pump with unleaded petrol.

INSTALLING THE PUMP

Connecting Hoses

Steps for connecting suction and discharge hoses to the pump securely.

Inlet Strainer and Debris Prevention

How to attach the inlet strainer and prevent clogging with debris.

OPERATION

Priming the Pump

Instructions on how to prime the pump with water before starting.

Starting the Engine

Step-by-step guide for starting a cold engine using choke and throttle.

Control During Operation

How to control pump output by adjusting engine speed and throttle.

SHUTTING DOWN

Engine Shutdown Procedure

Steps to safely shut down the engine and close the fuel valve.

MAINTENANCE

Air Filter Cleaning

Procedure for cleaning the air filter element using solvent and oil.

Spark Plug and Oil Management

Covers spark plug checks, oil changes, and pump storage preparation.

ENVIRONMENTAL PROTECTION

Used Oil Disposal

Guidelines for responsible disposal of used engine oil.

TROUBLESHOOTING

Engine Starting Issues

Common causes and solutions for the engine failing to start.

Engine Stopping Issues

Solutions for when the engine stops and will not restart.

Pump Priming Problems

Troubleshooting steps when the pump does not prime correctly.

Low Pump Output

Diagnosing and resolving issues causing low output from the pump.

SPECIFICATION

Technical Specifications

Detailed technical data including dimensions, weight, and performance ratings.

COMPONENT PARTS - GENERAL

General Component Identification

Overview of the main assemblies and parts of the pump.

COMPONENT PARTS - PUMP ASSEMBLY

Pump Assembly Breakdown

Detailed breakdown of pump assembly parts with numbers.

COMPONENT PARTS - ENGINE ASSEMBLY

Engine Assembly Diagram

Illustrated diagram showing the various parts of the engine assembly.

Engine Component List

A numbered list of engine components corresponding to the diagram.

GUARANTEE

Product Guarantee Terms

Details on the product guarantee, validity, and conditions.

DECLARATION OF CONFORMITY

Compliance Directives

Lists the directives and standards the product complies with.

A SELECTION FROM THE VAST RANGE OF

Clarke Quality Products

Advertises other Clarke product categories and contact information.
