OVERVIEW
1 Inlet Strainer/filter 12 Suction Chamber Drain Plug
2 Inlet Adaptor/locking ring with O-ring 13 Plug spanner/tommy bar
3 Water Filler Plug 14 Fuel Shut-off Valve
4 Outlet Adaptor/locking ring with O-ring 15 Choke Lever
5 Fuel Filler Cap 16 Throttle Lever
6 Air Filter Housing 17 Starter Recoil
7 Carburetor Drain Plug 18 ON/OFF Switch
8 Spark Plug 19 Oil Drain Plug
9 Suction Chamber Bolt 20 Oil Filler and Dipstick
10 Inlet or Suction Chamber 21 Rubber feet/fixings
11 Hose Securing Clips
