17
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
COMPONENT PARTS - ENGINE ASSEMBLY
No Description No Description
1 Fuel Tank Cap 31 Air Deflector
2 Fuel Strainer 32 Oil Drain Plug
3 Fuel Tank 33 Gasket
4 Tension Spring 34 M6 x 12 Bolt
5 Governor Arm 35 Suppressor
6Nut M6 36Crankcase
7Gasket 37Pin
8 Governor Lever 38 Oil proximity Sensor
9 Governor Rod 39 Bolt M6 x 15
10 Governor Spring 40 Bearing 205
11 Bolt 41 Governor Gear
12 Governor Assembly 42 Woodruff Key
13 Bolt M6 x 10 43 Bearing Cap
14 Starter Cover 44 Big End Bolt
15 Spring 45 Crankcase Gasket
16 Recoil Starter Assembly 46 Oil Dipstick
17 Spring 47 Sealing Ring
18 Starting Pawls 48 Crankcase Cover
19 Pin 49 Bolt M8 x 35
20 Clip Spring 50 Starting Handle
21 Starting Engagement Disc 51 Starting Cord
22 Bolt M6 x 15 52 Wingnut
23 Bolt M6 x 12 53 Air Cleaner Cover
24 On/Off Switch 54 Filter Sponge
25 Recoil Cover 55 Air Cleaner Base
26 Flywheel Nut 56 Nut M6
27 Starting Claw 57 Intake Duct Assembly
28 Fan 58 Bolt M6 x 25
29 Flywheel Assembly 59 Ignition Block Assembly
30 Oil Seal 60 Cylinder Head Stud
To Next Page
