Clarke TIGER1700 User Manual

6
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
OVERVIEW
NO DESCRIPTION NO DESCRIPTION
1 Fuel Tank Cap 9 Fuel Valve
2 Fuel Tank 10 Throttle
3 Spark Plug 11 Engine On/Off Switch
4 Choke 12 Oil Filler Cap
5 Gun Assembly 13 Water Outlet
6 Lance 14 Detergent Hose
7 Air Filter Cover 15 Water Inlet
8 Recoil Starting Handle 16 Bypass Drain Hose
78
9
10
11
1
2
3
4
5
12
6
13
14
15
16
